MICRON TXR
PLUS
RECEIVER
TO SWITCH ON
Press and release [ON/OFF] button. Unit will sound a
three note sequence and the four LEDs will illuminate.
TO SWITCH OFF
Press and release [ON/OFF] button. Unit will sound a
single low note.
TO ADJUST VOLUME AND SELECT
VIBRATING ALERT
Use [VOLUME +] and [VOLUME -] buttons.
The unit will give a two-tone ascending or descending
beep at the new volume setting.
There are 8 different volume settings available.
Vibrating alert is selected by pressing [VOLUME -]
again, when the unit is already at its lowest volume
setting.
"REGISTRATION" MODE
When the TXR Plus system is used for the first time,
it is necessary to "register" the transmitter with the
receiver, so that the receiver can "learn" its unique
1 0
identification code. Before starting this procedure,
ensure that the TXR Plus transmitter is switched OFF,
then proceed as follows -
1. With the TXR Plus receiver already switched on,
press and hold down its [ON/OFF] button. After about
two seconds, the top LED will start to flicker rapidly.
Release the [ON/OFF] button.
2. Switch on the TXR Plus transmitter unit. The top
LED on the TXR Plus will stop flickering and illuminate
constantly for a brief period and the TXR Plus will emit
a single beep.
3. The second LED on the TXR Plus will then start
flickering for a moment and will then illuminate con-
stantly for a brief period, followed by another single
beep.
4. This will be repeated for the third and fourth LEDs
down.
5. All four LEDs on the TXR Plus will then start to flick-
er. Switch the TXR Plus receiver OFF.
6. Switch the TXR Plus receiver on again and the sys-
tem is now ready for use.
7. Note that if an error has been made, registration
mode can be cancelled at any time, by switching the
receiver off.
8. Registration data is held in non-volatile memory and
so is held indefinitely when batteries are removed. It is
not therefore necessary to repeat this procedure at
any time.
9. If registration mode is entered accidentally, then
simply switching the receiver off will terminate regis-
tration mode and prevent any corruption of the regis-
tration data.

OUT-OF-RANGE WARNING

The TXR Plus receiver incorporates an out-of-range
warning tone, which will sound when the receiver
recognises a transmission from a bite alarm, but the
transmission is "breaking up". Depending on the condi-
tions of use, signals from the bite alarm may also not
be received at all, at the extremes of range, which will
result in missing "beeps".
Determining the limits of range is most conveniently
done with the bite alarm in range test mode (consult
the operating instructions of your bite alarms for
details of how to select range test mode). As the limit
of range is reached, the test signal will begin to break
up, with missing "beeps", interspersed with the dis-
tinctive "crash" tone, indicating out-of-range.
Note that the out-of-range tone also operates when
the bite alarms are in normal operation mode.
USER CONFIGURABLE LEDs
The receiver is equipped with four high-brightness
white LEDs. A set of interchangeable coloured lenses
are provided, so that the user may assign any colour
lens, to any LED, as desired. To fit a new lens, simply
lever the existing lens out by inserting a screwdriver
or similar in the slot underneath the lens, at the side
of the case, taking care not to scratch the surface.
BATTERIES
The TXR Plus model runs from 2 x 'AAA' NiMH
rechargeable batteries (supplied) or can also be used
with standard 'AAA' alkaline non-rechargeable cells, if
the recharging feature is NOT in use.
IMPORTANT SAFETY WARNINGS
WARNING: DO NOT UNDER ANY CIRCUMSTANCES
ATTEMPT TO USE ALKALINE OR OTHER NON-RECHARGE-
ABLE BATTERIES WITH THE RECHARGING FEATURE. USE
ONLY THE NICKEL METAL HYDRIDE BATTERIES SUPPLIED.
FAILURE TO OBSERVE THIS MAY RESULT IN RISK OF FIRE,
EXPLOSION, BATTERY LEAKAGE OR PERSONAL INJURY
AND WILL INVALIDATE THE WARRANTY. FOX WILL NOT BE
HELD LIABLE FOR ANY DAMAGE OR INJURY SO CAUSED.
