BRACKET COMPONENTS

1. LOCKING BRACKET
2. BUZZ BAR CLAMP
3. RUBBER CLAMP INSERT
To fit Stalker, Sky, Horizon and
A-Pods.
4. RUBBER CLAMP INSERT
To fit Quattro and X-Pods plus
Rod-Lok buzz bars and Euro
buzz bars.
5. RUBBER CLAMP INSERT
To fit 3 rod Goal Post buzz
bars.
6
1 2
3 4
TRANSMITTER BRACKET
FITTING INSTRUCTIONS
1. Select the correct rubber inserts to fit
your buzz bar. Fit the clamp onto the bar.
2. Slide the locking bracket onto the clamp mak-
ing sure the tapered ends to the clamp are slot-
ted into the bracket the correct way, as shown
below.
