Get to know your modem
Power DSL
Light State Meaning
Power On Modem has power. Flashes while booting
up or during updates.
Off Modem has no power.
DSL On Modem has established a connection.
Flashes during connection attempt.
Off Modem has no connection.
Internet On Modem is online.
Off Modem is offline.
WiFi On WiFi is enabled.
Off WiFi is disabled.
Internet WiFi WPS USB L AN 1 L AN 2
Light State Meaning
WPS On Flashes during a WPS connection attempt
(may take up to 2 minutes). Remains on for
~5 minutes after successful connection.
Off WPS mode not in use.
USB On USB device is ready to use. Flashes while a
new USB device is booting up.
Off No USB device plugged into the USB port.
LAN 1-4 On Device(s) plugged into modem's LAN
ports.
Off No device(s) plugged into modem's LAN
ports.
