aoyue 950 Instruction Manual

Smd hot tweezers

Advertisement

Quick Links

950/ 950+
SMD HOT TWEEZERS
Instruction Manual
Thank you for purchasing Aoyue 950 / 950+
temperature controlled soldering station.
Please read the manual before using the unit.
Keep manual in accessible place for future reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 950 and is the answer not in the manual?

Questions and answers

Summary of Contents for aoyue 950

  • Page 1 950/ 950+ SMD HOT TWEEZERS Instruction Manual Thank you for purchasing Aoyue 950 / 950+ temperature controlled soldering station. Please read the manual before using the unit. Keep manual in accessible place for future reference.
  • Page 3: Table Of Contents

    TABLE OF CONTENTS Package Contents and Specifications……………….. 4 Care and Safety Precautions ………….………..…….. 5 Assembly Instructions ………………………………..6 Operating Instructions ………...……….…..…..…….. 7 Soldering Tip Care and Maintenance ……………….. 8 Tip Temperature Cleaning When not in use Hand piece Assembly …………. ………………….….… 9 Testing the heating element ……...………………….
  • Page 4: Package Contents And Specifications

    Solder Iron Stan Assembly guide ..1 pc. Power Cord ..1 pc. Aoyue 950+ Same as the 950 with an additional: Soldering Iron ..1 pc. Power Consumption...
  • Page 5: Care And Safety Precautions

    CARE and SAFETY PRECAUTIONS CAUTION: Misuse may cause injury and physical damage. For your own safety, be sure to comply with the following precaution. ● Temperature may reach a high of 480°C when turned on. - Do not use near inflammable/flammable materials. - Do not touch heated parts, can cause severe burns.
  • Page 6: Assembly Instructions

    ASSEMBL Y INSTRUCTIONS I. SOLDERING IRON HOLDER Dampen the cleaning sponge with water, squeeze it dry and place it in its base. SOLDERING IRON STAND III. SOLDERING IRON / TWEEZERS Attach the soldering iron or tweezers to the receptacle connector at the bottom right area of the main unit.
  • Page 7: Operating Instructions

    OPERATING INSTRUCTIONS Follow procedures shown in the “Assembly Instructions”. Turn on the unit. Turning the control knob clockwise increases the desired (SET) temperature settings, while turning the knob counter-clockwise decreases the desired (SET) temperature settings. When the heater lamp blinks on and off then it means that the tip temperature has reached the set temperature and is ready for use.
  • Page 8: Soldering Tip Care And Maintenance

    SOLDER TIP CARE and MAINTENANCE Tip Temperature If the tip temperature is too high, it decreases the life of the tip. So we suggest you to use the lowest *possible* tip temperature when sol- dering. This not only prolong life of the tip, it also quickens heat recov- ery and decreases harm to sensitive components.
  • Page 9: Hand Piece Assembly

    HAND PIECE ASSEMBL Y The hand piece may be disassembled for troubleshooting and repair: Turn off main station and unplug from power source. Detach the Soldering Iron Receptacle (“15” ) from the main unit. Turn the Copper Nut, (“1” ) counter clockwise to loosen it. Pull out the Tip Enclosure (“2”...
  • Page 10: Testing The Heating Element

    TESTING THE HEATING ELEMENT To test if the heating element is in working condition: Cool down assembly to room temperature before continuing the tests below: Follow “disassembling the hand piece” guide. Do the following tests on the hand piece PCB board: Resistance value of heating element 18 —...
  • Page 11: Troubleshooting Connections

    TROUBLESHOOTING CONNECTIONS The 5 pin socket can be tested to detect faults in the hand piece: Before plugging in the hand piece conduct the conti- Pins 4 & 2 ∞ nuity test as shown: Pins 4 & 1 ∞ If any of the combination registers a short re- Pins 5 &...
  • Page 12: Replacing Soldering Iron Cord /Fuse

    REPLACING SOLDERING IRON CORD /FUSE When cord is proven to be faulty follow the steps to replace the cord: Follow the steps in disassembling the hand piece. Make a brief illustration of wire configuration in the PCB. Unsolder the wires connecting the hand piece PCB and cord to- gether.
  • Page 13: Basic Troubleshooting Guidelines

    BASIC TROUBLESHOOTING GUIDE WARNING : To avoid personal injury or equipment damage, disconnect power cords before making any servicing to the equipment, or unless instructed otherwise in the trouble- shooting procedures. PROBLEM 1: THE UNIT HAS NO POWER /MAIN POWER LED DOES NOT LIGHT UP Check if the unit is switched ON.
  • Page 14 BASIC TROUBLESHOOTING GUIDE PROBLEM 3: SOLDERING IRON TEMPERATURE IS INTERMITTENT Description: Main power LED lights up and so does the heater LED but sol- dering iron temperature rises and falls uncontrollably. SOLUTION: Soldering iron plug may be loose from the receptacle unplug the ◆...
  • Page 15: Replacement Soldering Tips

    REPLACEMENT SOLDERING TIPS...
  • Page 16 Manufacturer: AOYUE INTERNATIONAL LIMITED Jishui Industrial Zone, Nantou, Zhongshan City, Guangdong Province, P.R.China http://www.aoyue.co...
