Q u i c k S t a rt G u i d e
012-15926A
PS-3600
Front Camera Port
Microphone
Screen
9.6"(24 cm)
diagonal
1280 by 800p
Home Button
Ruggedized Case
Volume Control
Interface View
Interface Battery
Status LED
USB-A Communication Port
ON/OFF Button
PASPORT Input 2
PASPORT Input 1
Interface
VOLTAGE INPUT
Micro USB
Temperature
ON/OFF Button
Probe Port
(±10V MAX)
Charging
Port
Side View
USB Charger with
Micro USB-B to
USB-A Cable
Earphone Port
Rear
Camera
800-772-8700 (US)
+1 916 462 8384
www.pasco.com
support@pasco.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for PASCO SPARK LXi
Summary of Contents for PASCO SPARK LXi
- Page 1 Q u i c k S t a rt G u i d e 012-15926A SPARK LXi Datalogger PS-3600 Front Camera Port Microphone Screen 9.6”(24 cm) diagonal 1280 by 800p Home Button Ruggedized Case Volume Control Interface View Interface Battery...
- Page 2 • Charging: To charge both the SPARK LXi screen and the interface, connect the USB charger to the Micro USB port on the interface using the Micro USB cable. Initial charging time may be three hours or longer depending on the power source and the condition of the batteries.
- Page 3 Connecting Sensors Wireless - Connect to the device wirelessly through the PASCO Data Collection Software. PASPORT - Plug a PASPORT Sensor into one or both of the PASPORT Input Ports. The PASCO software will automatically identify the sensor. If PASPORT sensors are not detected by the device, press the interface ON/OFF button and verify that the interface LED blinks green (interface is awake).
- Page 4 +1 916 462 8384 (worldwide) Email: support@pasco.com 800-772-8700 (U.S.) The Quick Start Guide may be updated periodically. For the latest revision of this Quick Start Guide, visit the PASCO Web site at www.pasco.com/manuals and enter the product number, PS-3600, in the text window.
