- Page 1 HDMI EXTENDER OVER 5 COAXIAL CABLE PART #960 OPERATING INSTRUCTIONS...
- Page 2 HDMI cables must be customized when the length reaches over 10 meters. 3) SCP’s HDMI Extender 960 has the ability to auto adjust the buffering and amplifying. Series con- nection of the SCP 960 achieve long distance transmissions of HDMI signals. When two pairs or more SCP 960s are stacked together, they can be used to create a larger distribution or daisy chained.
-
Page 3: Table Of Contents
HDMI EXTENDER OVER 5 COAXIAL CABLES PART# 960 Contents • Product Overview • Features • Package Contents • Connections and Operations • Specifications • Panel Descriptions • Typical Application • Maintenance • Product Service • Provided Service • Mail-In Service •... -
Page 4: Product Overview
HDMI EXTENDER OVER 5 COAXIAL CABLES PART# 960 PRODUCT OVERVIEW FEATURES • Very simple operation of the one pair as a full functional module. • Use five coaxial cables to substitute HDMI cable to achieve long distance transmissions. • Transmission distance reaches up to 100 meters under 1080p video format. - Page 5 HDMI EXTENDER OVER 5 COAXIAL CABLES PART# 960 Structured Cable Products reserves the right to make changes in the hardware, packaging and any accompanying documentation without prior written notice. Warning: To reduce the risk of fire, electric shock or product damage: 1.
-
Page 6: Package Contents
3) Connect the HDMI output such as HD-LCD, HD-DLP into 960-B. 4) Connect the IR TX UNIT into 960-A IR TX; Connect the IR RX UNIT into 960-B IR RX. 5) DIP switch description. -
Page 7: Specifications
HDMI EXTENDER OVER 5 COAXIAL CABLES PART# 960 Specifications Operating Temperature Range -5 to +35°C (-41 to +95 °F) Operating Humidity Range 5 to 90 % RH (no condensation) Input Video Signal 0.5-1.0 volts p-p Input DDC Signal 5 volts p-p (TTL) DTV/HDTV;... -
Page 8: Panel Descriptions
HDMI EXTENDER OVER 5 COAXIAL CABLES PART# 960 Panel Descriptions Front Panel 1- ISP, for update the firmware of the product. 2. DIP switch, for EDID setting. 3. Power input, 5VDC . 4. IR TX output. 5. HDMI input. 6. Coaxial outputs. -
Page 9: Typical Application
HDMI EXTENDER OVER 5 COAXIAL CABLES PART# 960 Typical Application Maintenance Clean this unit with a soft, dry cloth. Never use alcohol, paint thinner or benzine to clean this unit. Product Service Provided Service 1) Damage Requiring service: The unit should be serviced by qualified service personnel if: •... -
Page 10: Mail-In Service
HDMI EXTENDER OVER 5 COAXIAL CABLES PART# 960 Mail-In Service When shipping the unit, carefully pack and send it prepaid, adequately insured and preferably in the original carton. Include a letter detailing the complaint and provide a daytime phone and/or email address where you can be reached.
