Summary of Contents for Brooks FireTracker FT2GAS
- Page 1 Operation / Technical Manual FT2GAS Rev 1.3 Gaseous Extinguishing System FT2GAS M320 Dec 2019...
- Page 2 Gaseous Extinguishing System FT2GAS Rev No. 1.3...
- Page 3 The Brooks CIE monitors the wiring conditions by using the end of line devices. However, it is not capable of detecting the internal conditions of any associated external equipment unless the system is specially arranged to monitor those conditions.
-
Page 4: Table Of Contents
Gaseous Extinguishing System FT2GAS Rev No. 1.3 Table of Contents About this Manual ..........................8 Purpose ............................. 8 Referenced Documents ......................8 FT2GAS TECHNICAL DESCRIPTIONS ..................9 System Overview ........................9 Features ..........................10 Specifications .......................... 11 Operation ..........................12 2.4.1 Display Layout ......................... - Page 5 Figure 8 External Buzzer Circuit Figure 9 FT2 Control board PCB Layout (SUB922) Figure 10 Gas Control board PCB Layout (SUB928) Figure 11 Brooks Warning Signs PCB Layout Figure 12 (Photograph 2) Rear of Local Control Station Figure 13 Local Control Station Schematics...
- Page 6 Gaseous Extinguishing System FT2GAS Rev No. 1.3 List of Tables Table 1 General Specifications ......................11 Table 2 System Controls ........................13 Table 3 Buzzer Indicating Patterns ......................14 Table 4 LED Flash Patterns ........................14 Table 5 System Indicating LEDs and flash Pattern ................14 Table 6 Display Fault LED Indications ....................
-
Page 7: Warning Signs
A.S. warning signs with voice & speaker Documentation Feedback If you have any comments or suggestions regarding this manual, please contact Brooks Technical Services. We welcome your valuable feedback to further improve our future manuals. Please include the following information: Product name and version number (if applicable) •... -
Page 8: About This Manual
ABOUT THIS MANUAL Purpose This manual is designed to be the reference point for the Brooks Dual Zone Gaseous Control System and provides the technical and operational instructions to the installer / user. The document is intended to be used by the end user, service and commissioning personnel. It provides detailed information required for installation, commissioning and operation. -
Page 9: Ft2Gas Technical Descriptions
System Overview A typical Brooks FT2GAS system is comprised of the following: • Brooks FT2 Dual Zone control board (SUB922) and Zone Display Board (SUB923) Brooks Gas Extinguishing Control board (SUB928) and Gas Display board (SUB929). • Switch Mode AC/DC Power Supply and backup batteries •... -
Page 10: Features
• Fully supervised system inoperative warning sign 24V output rated @ 0.5A maximum. Fully supervised 2 wire system outputs for level 1 and level 2 alarms to Brooks warning signs • (Level 1: alarm 1 [+/-] & Level 2: alarm 2 [-/+]) rated @ 3A maximum. Note: [+/-] & [-/+] means polarity changes accordingly to level 1 or 2. -
Page 11: Specifications
Gaseous Extinguishing System FT2GAS Rev No. 1.3 Specifications Table 1 General Specifications Feature Specification Mains Power Supply 230V AC, +/- 20%. Wattage 150W (maximum 5 A @28V) 2 x 12V sealed lead acid batteries up to 12 AH, refer to power supply calculations, Standby Battery APPENDIX D on page 39 Access Level 1: All the LED indicators are viewable through the locked transparent... -
Page 12: Operation
Gaseous Extinguishing System FT2GAS Rev No. 1.3 Operation 2.4.1 Display Layout The FT2GAS gaseous extinguishing control system display is shown in Figure 2 Figure 2 Dual Gaseous Extinguishing System Display Layouts All the control buttons and LEDs on the front display of the control panel, with the exception of the Service Master Abort switch, are a pushbutton covered with a polycarbonate overlay decal and clearly labeled with their function. -
Page 13: System Controls
Gaseous Extinguishing System FT2GAS Rev No. 1.3 2.4.2 System Controls The system controls can be carried out by operating the momentary push-button switches on the front display whilst the remote control is carried out by switches on the Local Control Station and / or the gas valves of the gas protection equipment. -
Page 14: Buzzer & Led Indicating Patterns
Gaseous Extinguishing System FT2GAS Rev No. 1.3 2.4.3 Buzzer & LED Indicating Patterns The CIE buzzer uses the following patterns to indicate the system conditions. Table 3 Buzzer Indicating Patterns Name Period On Time Off Time Pulsing Always OFF, only one beep when Key Pressed 40ms 40ms... -
Page 15: Fault Indications
Gaseous Extinguishing System FT2GAS Rev No. 1.3 Buzzer Type CIE Conditions LED Name Color Pattern Pattern Gas Discharge Disabled by the Gas Discharge Service Master Abort switch or Inhibited the gas lock-off valve controls Yellow Steady ON Gas Service Master Abort switch Service Master activated Abort... -
Page 16: Table 7 Gas Control Board Fault Led Indications
Gaseous Extinguishing System FT2GAS Rev No. 1.3 In addition to the LED indicators on the system front display, there are four yellow fault LED indicators located on the gas control board (SUB928) inside the cabinet. The internal LED indicating patterns are described in Table 7 below. -
Page 17: Cie Inputs And Outputs
Gaseous Extinguishing System FT2GAS Rev No. 1.3 CIE Inputs and Outputs 2.5.1 Fire Detection Zone Inputs The zone specifications and the compatible devices are listed Table 8 below. 2.5.1.1 ZONE INPUT CIRCUIT SPECIFICATIONS Table 8 Zone Input Item Description Number of zones in one CIE 2 zones Number of detectors per zone 0 –... -
Page 18: Control Input And Output
The output is 22-30V DC @ 0.5A and fully supervised for open and short circuit faults. The EOL resistor type is 20K, 1/2W or 1W, 1%, metal film. For more details, refer to the data sheet of the system inoperative sign in Brooks product datasheets in Appendix I 4.9.2 Warning Signs... -
Page 19: Fire Alarm / Do Not Enter And Evacuate Signs Output
The two-wire system of the alarm warning signs output is compatible with Brooks warning signs and tone / voice sounders. For more details, refer to the data sheet of the Brooks warning signs in Brooks product datasheets in appendix I on page 48. -
Page 20: Local Control Station (Lcs)
Both the EOL resistor and the active resistor are 47K, 1/2W or 1W, 1%, metal film. 2.5.2.7 Local Control Station (LCS) The FT2GAS system provides an interface to multiple remote gas control stations. Only the Brooks LCS can be connected to this interface. It includes the following four signals, •... -
Page 21: External Buzzer
Gaseous Extinguishing System FT2GAS Rev No. 1.3 2.5.2.8 External Buzzer The FT2 control board has an internal PCB mounted buzzer which meets the buzzer sound level requirement of 65dB at 1 metre distance with the door closed. If the internal buzzer sound level is insufficient, an external buzzer can be installed to the CIE front plate. -
Page 22: Table 11 Gas Control Board (Sub928) Dip Switch (8 Way) Sw1 Configuration
Gaseous Extinguishing System FT2GAS Rev No. 1.3 Table 11 Gas Control Board (SUB928) DIP Switch (8 way) SW1 Configuration Switch Status Purpose Bank Description On = 1 Off = 0 Number Switch number 200 milliseconds 5 seconds 10 seconds 15 seconds Gas release timer 20 seconds... -
Page 23: Power Supply Unit (Psu)
Gaseous Extinguishing System FT2GAS Rev No. 1.3 Power Supply Unit (PSU) 2.6.1 PSU Specifications The main power source of the standard FT2GAS system is a 150W switch mode power supply, the maximum current capacity is up to 5A @ 28V DC. The PSU supports the following: Total current required for the internal circuits •... -
Page 24: Psu Supervision
Gaseous Extinguishing System FT2GAS Rev No. 1.3 2.6.2 PSU Supervision The system constantly monitors the mains power supply, battery charger voltage and batteries and will initiate a PSU fault if the voltage of the charger or batteries exceeds the limits as in Table 13. Table 13 Power Supply Supervision Characteristics Characteristics Threshold... -
Page 25: Installation And Commissioning
Rev No. 1.3 INSTALLATION AND COMMISSIONING The installation and commissioning of Brooks FT2GAS shall be carried out by qualified installers following the requirements of all the related current standards and regulations, such as AS1670.1, AS/NZ 3000 and AS/ACIF S-009. Additional procedures detailed in this chapter shall also be followed. -
Page 26: Functional Testing
“Fire Alarm” warning sign illuminates (it may flash, depending on the DIP switch setting). d) Audible Alert tone is activated (if Brooks sounder is used). e) Press “Silence Buzzer” button, the buzzer should mute. Press “Silence Alarm Devices” (if audible sounders are used) then press “Reset” to reset the alarm. -
Page 27: Gas Extinguishing System Test
Gaseous Extinguishing System FT2GAS Rev No. 1.3 3.3.2 Gas Extinguishing System Test 1. Simulate the actual alarm test in either one of the two zones following steps 3a) to 3d) under the “Alarm Test” in section 3.3.1.2 page 26 and check the following: •... -
Page 28: Fault Test
Gaseous Extinguishing System FT2GAS Rev No. 1.3 2. Lift up the “Gas Isolate” flap then press the switch, check the following: “Gas Isolate” lamp integrated in the switch body illuminates. • • “Gas Discharge Inhibited” LED on the FT2GAS panel illuminates. Simulate the first and the second alarms, and ensure that the initiated LED remains OFF •... -
Page 29: Appendices
Gaseous Extinguishing System FT2GAS Rev No. 1.3 APPENDICES Appendix A - Connections The following are the connection details and printed circuit board layouts of the FT2 Control board and Gas Extinguishing control board. The connection details to the remaining boards and equipment (PSU, display boards, LCS, and Warning Signs) are shown in the block wiring Diagrams in on page 55. -
Page 30: Table 14 Ft2 Control Board Connections
Gaseous Extinguishing System FT2GAS Rev No. 1.3 Table 14 FT2 Control Board Connections Designator Type Label Description Power Input from the AC/DC power supply. POWER IN 22-27.6V DC, <= 5A Removable screw terminal block External battery connection BATTERY 22-27.6V DC, <= 5A Removable Power output to the Gas Module power input POWER... -
Page 31: Ft2 Gas Extinguishing Control Board
Gaseous Extinguishing System FT2GAS Rev No. 1.3 4.1.2 FT2 Gas Extinguishing Control Board Figure 10 Gas Control board PCB Layout (SUB928) -
Page 32: Table 15 Gas Control Board Connections
Gaseous Extinguishing System FT2GAS Rev No. 1.3 Table 15 Gas Control board Connections Designato Type Label Description EARTH Earth connection to the gas module LCS +24V output, 22V-30V, <=0.5A Removable screw LCS GND terminal block LCS INTERFACE LCS remote gas release input LCS remote gas isolate input gas lock-off valve input from lock off LOCK-OFF I/P... -
Page 33: Warning Signs Pcb Layout
Gaseous Extinguishing System FT2GAS Rev No. 1.3 4.1.3 Warning Signs PCB Layout Figure 11 Brooks Warning Signs PCB Layout Table 16 Warning Signs DIP Switch Setting Status Switch Purpose 1 = ON Description Number 0 = OFF Single mode, the whole sign illuminates... -
Page 34: Table 17 Extinguishing System Warning Signs Connections
Notes: 1. Brooks warning signs require only 2 wire connection. The 4 wire option is provided for retrofit situations where an existing 4 wire warning sign circuit is installed. 2. Brooks audio (Alert/Evac) / voice sounder can be connected to the same two wire system as the warning signs. -
Page 35: Local Control Station
Gaseous Extinguishing System FT2GAS Rev No. 1.3 4.1.4 Local control station Isolate Figure 12 (Photograph 2) Rear of Local Control Station Table 18 Local control station connection Type Label Description 24V Supply from the control board Screw Connected internally to the gas release switch on the Terminal front of LCS, “MCP”... -
Page 36: Appendix B - System Fuse Details
Gaseous Extinguishing System FT2GAS Rev No. 1.3 Appendix B – System Fuse Details The system fuses are listed in Table 19 below. Table 19 Fuse Specifications Board Designator Circuit Protected Specification M205, glass sealed, fast blow or very fast blow, Main power input <= 5A, defined by the application. -
Page 37: Appendix C - Cable Types And Calculations
Gaseous Extinguishing System FT2GAS Rev No. 1.3 Appendix C - Cable Types and Calculations 4.3.1 General Requirement The CIE cable type and cable installation shall follow all the application related current standards and regulations, such as the AS/NZS 3000, AS/ACIF S-009, AS1670 and NZS4512 standards. 4.3.2 Real Cable Resistance The maximum system cable length determined primarily from its cable cumulated resistance. -
Page 38: Output Cable
Gaseous Extinguishing System FT2GAS Rev No. 1.3 Example: If the manufacturer specified cable resistance of a two-core cable is 0.02 Ohms per metre, the real resistance will be 0.04 Ohms per metre and the maximum zone cable length will be 50 / 0.04 = 1250 metres. -
Page 39: Appendix D - Power & Battery Calculation Spreadsheet
Real Cable Resistance 0. 0256 Ohm / Appendix D – Power & Battery Calculation Spreadsheet In order to configure the Brooks dual zone gaseous extinguishing system, a power calculation of shall be performed. The following Table 22 shows the quiescent and alarm current of FT2GAS, different warning signs, ancillary and optional equipment. - Page 40 Gaseous Extinguishing System FT2GAS Rev No. 1.3 = Total system quiescent current in Ampere = Quiescent standby power source time, normally 96 hours (non-monitored systems) and 24 hours (monitored systems) Capacity de-rating factor, typically 2 = Total system alarm current in Ampere = Alarm load standby power source time, normally 0.5 hour Note: In most of the applications, the output required to discharge the gas is only instantaneous i.e.
- Page 41 Gaseous Extinguishing System FT2GAS Rev No. 1.3 Typical calculations: Qiescent Alarm Current Current Total Alarm (mA) (mA) Current (mA) Items FT2GAS Local Control Station (LCS) “Fire Alarm / Do Not Enter” Sign “Fire Alarm / Evacuate” Sign “System Inoperative” Sign 3A Gas Discharge for 1 min Optional Tone / Voice Sounders Total Load current (mA)
-
Page 42: Appendix E - Commissioning Record
Gaseous Extinguishing System FT2GAS Rev No. 1.3 Appendix E – Commissioning Record Table 23 Resistance Check Modul Expected Resistance Feature Probe + Probe - Result Range (Ohms) Power input TB1 POWER IN + TB1 POWER IN - 8K - 54K Battery TB1 BATTERY+ TB1 BATTERY-... -
Page 43: Table 24 Pre-Commissioning Battery Cell Voltage Measurement Record
Gaseous Extinguishing System FT2GAS Rev No. 1.3 Table 24 Pre-commissioning Battery Cell Voltage Measurement Record Multimeter Probe Expected Battery Multimeter Probe + Multimeter Readings (V) Voltage Battery 1 Battery + Battery - > 10.7V Battery 2 Battery + Battery - >... -
Page 44: Appendix F - Equipment Record
Gaseous Extinguishing System FT2GAS Rev No. 1.3 Appendix F – Equipment Record Table 26 Equipment record Description Record FT2GAS Model No. FT2GAS Serial No. FT2GAS Date of Manufacturing Serial No. FT2 Main Control Firmware Module version Serial No. Control Firmware Module version... -
Page 45: Appendix G - Maintenance Record
Gaseous Extinguishing System FT2GAS Rev No. 1.3 Appendix G – Maintenance Record Table 27 Maintenance record Technician Signature & Description Name Date... -
Page 46: Appendix H -Spare Parts List
Gaseous Extinguishing System FT2GAS Rev No. 1.3 Appendix H –Spare Parts List Table 28 FT2GAS panel parts Component Item Description BAPS24V150W SM Power Supply 24V/6.25A Adj. CA107 16 Way Ribbon Cable Assembly 500+80mm CA125 34 Way Ribbon Cable Assembly 1 Metre SUB922 FT2 Main Control Module SUB923... -
Page 47: Appendix I Data Sheets
FT2GAS Gas Extinguishing System Control Panel Figure 14 Gas Extinguishing Control Panel The Brooks FT2GAS comprises a 2 zone conventional CIE (AS7240.2) to which a plug-in gas control board is added. The combination of the CIE and plug-in gas extinguishing control board is designed to comply with the Detection, Actuation and Control Systems section of AS4214 2002 Gaseous Fire Extinguishing Systems. -
Page 48: Figure 15 Extinguishing System Warning Signs
They provide a suitable visual warning in the risk area when a gas extinguishing system is installed. Designed for use with the Brooks FT2GAS Conventional 2 zone Gas Control Panel the LED based design allows for the warning sign to be configured for single line operation e.g. “FIRE ALARM” or “DO NOT ENTER”... -
Page 49: Table 31 Warning Signs Specifications
Gaseous Extinguishing System FT2GAS Rev No. 1.3 Standard Configurations Brooks warning signs are available in the following standard configurations: BWS-FA “FIRE ALARM” only BWS-DNE “DO NOT ENTER” only BWS-EVA “EVACUATE” only BWS-ESI “EXTINGUISHING SYSTEM INOPERATIVE (pictured above) BWS-FDNE “FIRE ALARM – DO NOT ENTER combination (pictured above) BWS-FEVAC “FIRE ALARM –... -
Page 50: Local Control Station Blc1
The Local Control Station (BLCS1) provides for the manual release and discharge inhibit of the gas extinguishing agent. BLCS1 is interfaced to Brooks FT2GAS control panel via a supervised 4 wire connection. The GAS RELEASE function provides a manual initiate switch, incorporating a two-step action which initiates the normal system discharge sequence including fire and evacuation alarms, time delays, and equipment shutdowns and overrides the discharge inhibit switch. -
Page 51: Tone And Voice Sounders
Tone only relies upon the occupant’s awareness of the tones meaning and purpose. The Brooks electronic sounder consists of a speaker and digital voice/tone module which can be custom programmed for tonal frequency, voice message and language to meet specific client needs. - Page 52 Rev No. 1.3 Operation The BROOKS electronic sounder has two inputs, typically used for Alert and Evacuation but may also be two evacuation signals providing the same tone but differing language messages. The sounder requires a 24Vdc signal applied at the appropriate polarity. When power is applied to the digital voice/tone module the unit will sound the tone for approximately 10-12 seconds followed by a digital voice message.
-
Page 53: Gas Strobe Interface (Sub938)
4.9.5 Gas Strobe Interface (SUB938) The strobe interface module shown in Figure 18, is designed to interface Brooks warning sign output of FT2GAS to a dual strobe e.g. amber / red combo. Table 15 Gas Control board Connections page 32, terminal block TB3 explains the states for warning signs. -
Page 54: Table 33 Polarity State Sequence For Warning Signs
Gaseous Extinguishing System FT2GAS Rev No. 1.3 MUTE BUZZER / L1 STROBE terminal allows for connection of an external momentary switch, which when activates will turn of the buzzer and the L1 strobe. Outputs: (all outputs are 24Vdc) 1. Buzzer 2. -
Page 55: Block Wiring Diagram
Gaseous Extinguishing System FT2GAS Rev No. 1.3 BLOCK WIRING DIAGRAM Figure 19 FT2GAS Block Wiring Diagram... -
Page 56: Figure 20 Ft2Gas Warning Signs Connection Diagram
Gaseous Extinguishing System FT2GAS Rev No. 1.3 Figure 20 FT2GAS Warning Signs Connection Diagram... -
Page 57: Figure 21 Warning Sign With Voice And Timer Connection
Gaseous Extinguishing System FT2GAS Rev No. 1.3 Figure 21 Warning Sign with Voice and Timer connection... - Page 58 P.O. Box 7050 Silverwater NSW 1811 4 Pike Street Rydalmere NSW 2116 Ph: 02 9684 1466 Website: www.Brooks.com.au 9/71 Victoria Crescent, Abbotsford VIC 3067 Ph: 03 9879 5294 P.O. Box 101 Woodville SA 5011 729A Port Road, Woodville, SA 5011 Ph: 08 8347 0000 P.O.
