Automatic Inductive Urinal Flusher User Manual
Use (Urinal cycle steps)
1. The photoelectric cell is covered by the user;
2. After 2 seconds the there is the first cleaning flush for 2 seconds;
3. Photoelectric cell covering time depends on how long the user stands in front of it;
4. Photoelectric cell gets uncovered;
5. After 3 seconds there is the final flush, longer then the first
Simple manufacture, it includes one stop valve, one filter and one flushing pipe.
Primary Application
Public places.
Technical Data
Working pressure: 0.1 – 0.4 Mpa
Power supply: DC6V (four 1.5V "AAA" size alkaline batteries)
Inlet calibre: G1/2''
Recognition range: 35 cm
Installation mode: Exposed
Checking List
N°
1
Main body
2
Flushing pipe
3
Decorative cover
4
Flushing controller
5
Alkaline battery
6
Special spanner
7
User manual
8
Sealed ring
Notes
1. Check carefully packed parts before installation and contact us for any
further request.
2. All parts are packed in suitable bags, please do not bump them excessively.
Names of the parts
SE 33
Touch less battery-operates Urinal Flusher
Parts
1
Quantity
Remarks
1
1
2
2
4
1.5V "AAA"
1
1
1
Advertisement
Table of Contents
Related Manuals for Remer SE 33
Summary of Contents for Remer SE 33
- Page 1 SE 33 Automatic Inductive Urinal Flusher User Manual Touch less battery-operates Urinal Flusher Use (Urinal cycle steps) 1. The photoelectric cell is covered by the user; 2. After 2 seconds the there is the first cleaning flush for 2 seconds;...
- Page 2 Installation NOTE: Before installation, be careful to turn off water supply and check the pipeline to keep it clean. 1 : Install/change battery. Unscrew the closing screw (A) on the back of the main body. Detach the control unit shell (2). Unscrew the closing screw (B) in front of the control unit (3).
- Page 3 2 : Install the faucet. Place the decorative cover (A) on the water hose and screw the main body (1). Connect one end of the flushing pipe to the main body and the other to the urinal (2). Maintenance When faucet works for the first time, light flashes several times...
- Page 4 In case the faucet has no action (no water out), this may be due to: Not installed batteries. Install them. Shut off water supply. Turn it on. Not ready contacts. Check them. In case the induction distance is too much, clean the inductive window with a soft cloth.
