REAR CONNECTIONS

1
1 XLR Outputs. Connect to your preamp or amp
with XLR cables.
2 RCA Outputs. Connect to your preamp or amp
with RCA cables.
Note: Both RCA and XLR outputs are active at the
same time.
3 Firmware Update Slot. Follow the directions at
schiit.com/firmware to create a microSD card to
insert here when it's time to upgrade firmware.
NO IT WILL NOT PLAY YOUR MUSIC FILES.
4 Coaxial Input. Connect to a digital source with
coaxial output using a coaxial cable.
2
4
3
6
SCH-04-2
0A19C2832
7
5
5 Optical Input. Connect to a digital source with
Toslink output using a Toslink cable.
6 USB Input. Connect to a computer or streamer
using a minimum USB 2.0-rated cable, 2M or less
in length.
SCH-04-2
0A19C2832
7 Power Switch. Up for music, down for silence.
You get the picture.
8 Power Inlet. Connect the power cord here, or
#7 won't work. Don't connect a 115VAC Bifrost to
a 230V power source, or you'll blow the fuse.
