Front Controls; Remote Control - Schiit True Multibit Autonomy Bifrost Owner's Manual

FRONT CONTROLS

1 Input Select. Press the button to cycle through
Coaxial, Optical, and USB inputs.
2 Input LEDs. From left to right, this indicates the
USB, optical, and coaxial inputs.
Note 1: The USB input will be skipped unless a valid USB
source is connected to Bifrost 2.
Note 2: The input light will flash if Bifrost 2 is muted.
You can mute and unmute via the remote control.
3 Remote Window. The remote control
communicates through this window.
4 Invert LED. When the output is inverted, this
LED will light. You can invert and de-invert via
the remote only.
1 2

REMOTE CONTROL

The remote allows you to cycle
through inputs, mute the output, and
invert the output.
Changing the Battery
1. Push the remote open by inserting the end
of an open paper clip into the hole in the back
and pressing firmly.
3. Replace the battery inside with one of the
same type.
4. Reassemble the remote by first inserting the
clear LED in the front, then dropping the panel
down onto the matching magnets.
3 4
