Summary of Contents for Hans Grohe AXOR Urquiola
- Page 1 Installation Instructions / Warranty Urquiola 11626XX1...
-
Page 2: Installation Considerations
Installation Considerations • For best results, Hansgrohe recommends that higher than 120°F. In Massachusetts, the maxi- this unit be installed by a licensed, professional mum output temperature of the shower valve can plumber. be no higher than 112°F. • Please read over these instructions thoroughly •... - Page 3 Consideraciones para la instalación no debe exceder los 120°F. En Massachusetts, • Para obtener mejores resultados, la instalación debe estar a cargo de un plomero profesional la máxima temperatura de salida de la válvula matriculado. de la ducha no debe exceder los 112°F. •...
- Page 4 English Installation ½" Installation Wrap the nipple with Teflon tape. Install the mounting piece. 8 mm ¾" Installation 8 mm The mounting piece should extend 1⅛" outside the surface of the finished wall. Seal the wall around the nipple using waterproof sealant. Failure to seal the wall may lead to water damage.
- Page 5 Français Español Installation Instalación Enveloppez les filets du mamelon avec du ruban Envuelva las roscas del niple con cinta de Teflon. Téflon. Instale la pieza de montaje. Installez la pièce de montage. Une partie de 1⅛ po de la pièce de montage se El extremo de la pieza de montaje debe sobresalir trouver à...
- Page 6 English Position the support over the mounting piece. Mark the position of the screw hole. Drill the screw hole. Install the anchor. Ø 6 mm Seal the wall around the anchor using waterproof sealant. Failure to seal the wall may lead to possible water damage.
- Page 7 Français Español Placez le support sur la pièce de montage. Posicione el soporto sobre la pieza de montaje. Marquez le position de le trou de vissage. Marque la posicione del orificio para tornillo. Percez le trou de vissage. Perfore el orificio para tornillo. Installez la cheville.
- Page 8 Replacement Parts / Pièces détachées / Repuestos 916XX0 11x2 9669000 1x2 XX = colors / couleurs / acabados 00 = chrome 90000 = polished nickel 90000...
- Page 9 Cleaning Recommendation for Hansgrohe Products Modern bathroom faucets, kitchen mixers and showers consist of very different materials to comply with the needs of the market with regard to design and functionality. To avoid damage, it is necessary to consider certain criteria when cleaning. At the cleaning of the fittings and showers, in principle, it must be pointed out: •...
-
Page 10: Indications Importantes
• Pour le nettoyage avec produit vaporisé liquide, en aucun cas sur la robinetterie, mais au contraire aspergé sur le chiffon (torchon, éponge) et effectuer comme cela le nettoyage, car les aérosols peuvent pénétrer dans les ouvertures et fentes de la robinetterie et peuvent provoquer des détériorations. •... -
Page 11: Limited Consumer Warranty
Limited Consumer Warranty This product has been manufactured and tested to the highest quality standards by Hansgrohe, Inc. (“Hansgrohe”). This warranty is limited to Hansgrohe products that are purchased by a consumer in the United States or Canada after March 1, 1996, and installed in either in the United States or in Canada. WHO IS COVERED BY THE WARRANTY This warranty extends to the original purchaser only. -
Page 12: Exclusions And Limitations
EXCLUSIONS AND LIMITATIONS REPAIR OR REPLACEMENT (OR, IN LIMITED CIRCUMSTANCES, REFUND OF THE PURCHASE PRICE) AS PROVIDED UNDER THIS WARRANTY IS THE EXCLUSIVE REMEDY OF THE PURCHASER. HANSGROHE NEITHER ASSUMES NOR AUTHORIZES ANY PERSON TO CREATE FOR IT ANY OTHER OBLIGATION OR LIABILITY IN CONNECTION WITH THIS PRODUCT.
