1
TechBook
in.k1000+
full-featured color capacitive
touchscreen display keypad for spas
A touch of engineering magic!
Now with your own personal swim coach!
Now connects to the Internet of Things!

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the in.k1000+ and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Gecko in.k1000+

  • Page 1 TechBook in.k1000+ full-featured color capacitive touchscreen display keypad for spas A touch of engineering magic! Now with your own personal swim coach! Now connects to the Internet of Things!
  • Page 2: Table Of Contents

    Table of contents Warning ��������������������������������������������������������������������������������������������������������������������������������������������������������������������������� 2 Introduction ��������������������������������������������������������������������������������������������������������������������������������������������������������������������� 3 Overview - in�k1000+ dimensions ��������������������������������������������������������������������������������������������������������������������������������������� 4 - in�k1001+ dimensions ��������������������������������������������������������������������������������������������������������������������������������������� 5 Installation - Installation of in�k1000+ ������������������������������������������������������������������������������������������������������������������������������������� 6 - Drilling template ������������������������������������������������������������������������������������������������������������������������������������������������� 7 - Installation notes ������������������������������������������������������������������������������������������������������������������������������������������������� 9 - Connecting in�k1000+ to the spa pack �������������������������������������������������������������������������������������������������������������� 9 Keypad functions - in�k1000+ keypad layout ����������������������������������������������������������������������������������������������������������������������������������...
  • Page 3: Warning

    Compatible spa controllers: in�xm2, in�xe, in�yt, in�yj and in�ye with compatible software revision� Aeware®, Gecko®, and their respective logos are Registered Trademarks of Gecko Alliance Group� in�k1000+™, in�xm2™, in�xe™, in�yt™, in�ye™, in�yj™, in�tune™, in�stream™, in�stream 2, in�mix™, in�clear™, in�touch™ and in�therm™, and their respective logos are trademarks of Gecko Alliance Group�...
  • Page 4: Introduction

    A touch of engineering magic! Gecko’s new version of its in�k1000 capacitive touch screen display keypad boasts a new state of the art touch screen with more precise fingertip contact areas for accurate target selection, enabling easier and more precise interactions�...
  • Page 5: Overview

    Overview in.k1000+ dimensions Front view 7,49" (190 mm) Side view...
  • Page 6: In.k1001+ Dimensions

    Overview in.k1001+ dimensions Front view 6,23" (158 mm) Side view...
  • Page 7: Installation

    Installation Installation of in.k1000+ When installing the keypad on the spa, a minimum angle of 4 degrees must be respected� 4° To install the in�k1000+, use the drilling template provided in this section� Determine the mounting location and stick the template on the chosen location� Cut out an opening according to the template (see illustration)�...
  • Page 8: Drilling Template

    Installation Drilling template ø 0,19" 3,19" (5 mm) (90 mm)
  • Page 9 Installation Drilling template 1,5" (38 mm) ø 2,5" (64 mm)
  • Page 10: Installation Notes

    Installation Installation notes vent hole The vent hole on back of keypad should not be blocked� The back of the in�k1000+ should not be enclosed where water can gather, but instead in a cut out� keypad cover water Connecting in.k1000+ to the spa pack Main keypad in�k1000+ To connect the in�k1000+ keypad, simply insert its in�link connector into the appropriate keypad connector of the...
  • Page 11 Installation Installation errors Upon connecting the in�k1000+ to the spa pack you may see one of two error messages� Please follow the instructions in the message or contact your dealer for more information�...
  • Page 12: Keypad Functions

    Keypad functions in.k1000+ keypad layout direct to function selection wheel (settings and all-on or all-off key additional options) (one touch activation) mode selection wheel (settings and on-screen accessories) system messages and reminders interactive display icons (main spa functions) Sleep mode Touch the screen to exit sleep mode�...
  • Page 13: Start Or Stop Accessories

    Keypad functions Start or stop accessories To start or stop an accessory, touch the associated icon� Icons will become animated when their accessory is turned on and animation will stop when turned off� Icons on the screen will reflect the speed or state of the devices running on your spa�...
  • Page 14: Water Temperature

    Keypad functions Water temperature The temperature shown at the bottom of the screen indicates the current water temperature� Use the Up and Down icons to set the desired temperature� The set point will appear in blue� After 3 seconds without any change to the set temperature value the current water temperature will reappear in white�...
  • Page 15: Contrast Page

    Keypad functions Contrast page Use this page to change the display contrast� Sleep Press key to go directly into the sleep mode� In sleep mode, water splashing on the keypad can't inadvertently start/stop a pump� Settings In the Settings page you can access the following: •...
  • Page 16: Water Care

    Keypad functions Water Care The Water Care page will help you set up your ideal filtration and heating settings� Choose between Away from Home, Standard-Beginner, Energy Savings, Super Energy and Weekender, depending on your need� Touch the Water Care name to choose your setting� A green checkmark will appear on the selected icon to confirm your choice�...
  • Page 17: Modifying Schedules

    Keypad functions Modifying schedules To modify a Water Care category, touch the pencil icon at the right end of the desired Water Care to open the selected Water Care menu� Touch the Economy tab to change the economy setting and Filter cycle tab for the filtration settings (or schedules)� You can add economy or filtration schedules by touching the orange line labelled«...
  • Page 18: Reminders

    Keypad functions Reminders The in�k1000+ keypad will provide reminders about maintenance required on your spa, like rinsing or cleaning the filter� Every task has its own duration based on normal use� The Reminders menu allows you to check the time left before maintenance is required, as well as to reset the time once a task has been completed�...
  • Page 19: Keypad Settings

    Keypad functions Set date Here you can adjust the year, month and day� Simply swipe up and down the column you want to change and select the desired value� When you are done, touch the calendar icon at the right of the screen� Set time Here you can change the hour, minute and time format�...
  • Page 20: Temperature Units

    Keypad functions Temperature units Choose the desired units to display temperatures� Display page Use this page to change the display orientation� Contrast page Use this page to change the keypad contrast�...
  • Page 21: Language Select

    Keypad functions Language select Use this page to select the display language of the in�k1000+ keypad� Keypad lock/unlock (optional) When this option is enabled, the user can partially or completely lock the keypad� When the user wants to lock the keypad he is asked to select a 4-digit code� The same code will be needed to unlock the keypad�...
  • Page 22: Keypad Color (Optional)

    Keypad functions Keypad Color (optional) If this option is available (depending on the spa configuration), the keypad rim color can be changed� 8 pre-defined colors are available� If the in�mix is installed, the keypad rim color can also be associated to an in�mix zone�...
  • Page 23: Select Logo

    Keypad functions Select logo After confirmation, the keypad will reset to reconfigure the system� You will be asked to select the custom icons used in the sleep mode� Wi-Fi (in.touch) This page allows you to connect your in�touch module to a Wi-Fi network or to change its network�...
  • Page 24: Wi-Fi (In.touch 2)

    Keypad functions Wi-Fi (in.touch 2) When a in�touch 2 is detected, this network will appear� Miscellaneous This menu gives access to modify the Warm Weather option and info messages in the media center� Warm weather When pumps are running, they produce heat that may increase your water temperature�...
  • Page 25: Info Messages

    Keypad functions Info messages Press display/hide key to modify message display: If hide option is selected, smart winter mode message will only appear when a SWM purge is in action� Otherwise the message will always appear when the spa is in a SWM condition�...
  • Page 26: Swim Functions

    Keypad functions Swim functions This menu is available only if the Swim option is activated in the spa configuration� The Duration of all training drills and the Intensity of all pre-set training drills are set in this page� The number of available intensities depends on the swim spa configuration and on the selected training drill, whose name is displayed at the top of the screen�...
  • Page 27 Keypad functions Step time This page allows you to adjust the workout session step time� Step time applies to all training drills except Endurance, Power and Personalized� Preparation time This page allows you to adjust the Preparation time� The preparation allows the swimmer to take place between the time when he presses on the “Start”...
  • Page 28 Keypad functions Training Drills The Training Drills selection page allows you to choose the desired workout drill� The currently selected drill is highlighted and has a green checkmark� To select another drill, simply scroll through the list and click on its name� Endurance: In this training drill, the swimming workout will be executed at a constant intensity for the entire...
  • Page 29 Keypad functions Personalized workout edits This page allows you to create a personalized training drill� Simply draw the desired workout pattern on the screen and/or adjust each individual step to the desired intensity� The duration of the 20 available steps will be adjusted to fit the duration selected on the main screen�...
  • Page 30 Keypad functions Swim workout When you press the Start button, the preparation counter appears and starts to decrement, allowing the swimmer to get in position before the swimming session starts� From there, you can press Pause to suspend or Stop to interrupt the swim session and return to the main swim page�...
  • Page 31: In.stream 2 Functions

    Keypad functions in.stream 2 functions This menu is available only if the in�stream 2 audio station is detected in the spa accessories� The audio page will allow you to control the active audio source� Note that only the functions that apply to the selected source will be available�...
  • Page 32 Keypad functions Speakers settings Move the sliders to adjust the Balance, Fader and Subwoofer settings� The Fader and Subwoofer sliders will only appear in the Speakers menu if the corresponding speakers are available on the in�stream 2� Source menu To change the audio source, simply tap on the desired one� Note that only the sources available on the in�stream 2 will be displayed in the source menu�...
  • Page 33: In.clear Functions

    Keypad functions in.clear functions This menu is available only if the in�clear is detected in the spa accessories� The in�k1000+ keypad can be used with the in�clear sanitation system� The in.clear menu allows you to configure your maintenance settings and boost levels� The main in.clear menu shows the current status of the sanitation system, whether it is on and if it is generating bromine or not�...
  • Page 34 Keypad functions Modify the Boost level The Boost level is used to set the amount of boost required� As a rule, enter the number of bathers in the bath� Boost mode is automatically activated 5 minutes after starting a pump� Modify the maintenance level The maintenance level can be changed and must be tested with a bromine level tester�...
  • Page 35: In.mix Functions

    Keypad functions in.mix functions This menu is available only if in�mix is detected in the spa accessories� By default, in�mix selects Zone 2 when you access the menu� synchronization/ desynchronization icon color wheel rainbow icon zone 1 mode selection zone 2 wheel: in�mix icon zone 3...
  • Page 36: Error Messages

    Error messages The list below shows the different error messages that can appear on the home screen� Refer to the troubleshooting and error codes section of the TechBook for your spa pack system� Please note that if you are in a swim spa configuration, the message may be followed by "Master" or "Slave" to designate from which pack the error is coming�...
  • Page 37: Feature Matrix

    Feature matrix The following table presents the features and/or options available for the in�k1000+ keypad and the earliest software version at which this feature/option is available� All later versions greater than the earliest version continue to support the feature� Also note that the in�k1000+ includes all features and/or options that were available on the in�k1000� Keypad functions Earliest support Swim functions...
  • Page 38: Specifications

    Specifications Model Part number Description in�k1000+ 0607-005033 IN�K1000-V2-BK-GE1 in�k1000+ 25' cable 0607-005036 IN�K1000-V2-BK-25FT-GE3 in�k1000+ chinese 0607-005035 IN�K1000-V2-BK-CHINESE-GE1 in�k1001+ 0607-008087 IN�K1001-V2-CL-GE1 in�k1001+ 25' cable 0607-008088 IN�K1001-V2-CL-25FT-GE2 Environmental Operating temperature: -4°F (-20°C) to 149°F (65°C) Storage temperature: -22°F (-30°C) to 185°F (85°C) Water ingress protection: IPX5 Mechanical...
  • Page 39 9919-101605-A Rev. 12-2018 Gecko Alliance 450 des Canetons, Québec (Qc), G2E 5W6 Canada, 1.800.78.GECKO © Groupe Gecko Alliance inc., 2018 All trademarks or registered trademarks www.geckoalliance.com are the property of their respective owners. Printed in Canada...
