FX-WRZSST-110 Wireless Sensing System Tool

Installation Instructions

FX-WRZSST-110
Applications
The FX-WRZSST-110 Wireless Sensing System Tool is
a lightweight, portable, wireless receiver designed to
receive wireless Radio Frequency (RF) data
transmissions from Johnson Controls® FX-WRZ
Series Wireless Room Sensors in One-to-One sensing
system site survey applications. The FX-WRZSST-110
Tool also serves as a signal test receiver or site survey
tool prior to installing an FX-ZFR Series Wireless Field
Bus System.
Prior to installation, use the FX-WRZSST-110 Tool, to
verify the optimum locations for FX-WRZ Series
Sensors and the FX-WRZ7850 Receiver in
One-to-One wireless room sensing systems. You can
also use the FX-WRZSST-110 Tool to verify the
optimum locations for Johnson Controls FX-ZFR1810
Coordinators, FX-ZFR1811 Routers, and
FX-WRZ Series Sensors in wireless field bus
applications.
North American Emissions Compliance
United States
This equipment has been tested and found to
comply with the limits for a Class A digital device
pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection
against harmful interference when this equipment is
operated in a commercial environment. This
equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in
accordance with the instruction manual, may cause
harmful interference to radio communications.
Operation of this equipment in a residential area is
likely to cause harmful interference, in which case
the user will be required to correct the interference
at his/her own expense.
RF Transmitters: Compliance Statement
(Part 15.19)
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
1. This device may not cause harmful interference,
2. This device must accept any interference
Warning (Part 15.21)
Changes or modifications not expressly approved by
the party responsible for compliance could void the
user's authority to operate the equipment.
FX-WRZSST-110 Wireless Sensing System Tool Installation Instructions
Part No. 24-10563-20, Rev. —
and
received, including interference that may cause
undesired operation.
Issued April 12, 2011
1
