Overview
System overview
3.3
System overview
Item Symbol
1
2
3
4
5
6
3
1
Description
0
Power source
ON PS drive 4L T/P
Pivot support – 092-002112-00000
Hose support arm
Wire feeder - drive 4L (pivotable)
ON PS Trolly 55.2-2 drive 200/300C
Pivot support - 092-002634-00000
4
2
Figure 3-2
5
099-002112-EWM01
06.07.2012
