Nic; Node - Thecus i Series User Manual

3.5.2

NIC

Select "NIC" to change IP addresses of iSCSI data ports.
(Figure 3.5.2.2: there are 2 iSCSI data ports.)
User can change IP address by clicking the button "
column. There are 2 selections, DHCP (Get IP address from DHCP server) or
static IP.
Default gateway can be changed by clicking the button "
"Gateway" column. There is only one default gateway.
Jumbo frame setting can be changed by clicking the button "
"Jumbo frame" column. Default setting is Disable.
3.5.3

Node

Select "Node" to view the target name for iSCSI initiator.The node name of i
Series exists by default and can not be changed.
Figure 3.5.2.2
Figure 3.5.2.3
Figure 3.5.3.1
- 27 -
" in the "DHCP"
" in the
" in the
