1.0 Unpacking
Be careful not to damage the contents when unpacking the parts. Check that all parts are included in the
cardboard box. Keep the packaging materials in case your speaker needs to be relocated or serviced.
2.0 DALI KATCH ONE Buttons, indication LED's and Connections
2.1 DALI KATCH ONE Button and LED Overview
1
2
3
4
5
LED Indication
1. Bluetooth
2. HDMI
3. Optical (for TV)
4. Optical (for audio)
5. Mini-jack
6. Power on
7. Sound mode
Buttons
1. Source select (Toggle)
2. Bluetooth release
3. Power On/Off/Mute
4. Volume Down
5. Volume Up
6. Sound Mode (Toggle)
DALI KATCH ONE Manual
1
2
3
4
5
5
6
7
5

Advertisement

loading

Related Manuals for Dali KATCH ONE

Summary of Contents for Dali KATCH ONE

  • Page 1 Be careful not to damage the contents when unpacking the parts. Check that all parts are included in the cardboard box. Keep the packaging materials in case your speaker needs to be relocated or serviced. 2.0 DALI KATCH ONE Buttons, indication LED’s and Connections 2.1 DALI KATCH ONE Button and LED Overview LED Indication 1.
  • Page 2 2.2 DALI KATCH ONE connector overview 2.3 Remote control...
  • Page 3 1. Press and hold the Power ON/OFF button (Button 2) until the Power ON sound is played. 2. The indicator light (LED 6) is illuminated, and the KATCH ONE is ready for use. If your DALI KATCH ONE does not turn on, connect the mains charger (See 4.0) 3.2 Power OFF...
  • Page 4 DALI KATCH ONE earlier, and is within range. It is possible to have two devices paired to the DALI KATCH ONE at the same time. Both devices can play audio, but only one at a time via the DALI KATCH ONE.
  • Page 5 2. All connected devices are now released and you can re-engage the pairing. 5.3 Bluetooth Naming If you have more than one DALI KATCH ONE, it is possible to change the Bluetooth name of your DALI KATCH ONE. 1. Turn off the DALI KATCH ONE (See 3.2).
  • Page 6 6.0 Sound Mode The DALI KATCH ONE has two sound modes, Focus and Wide. To toggle between the two sound modes press the ‘Sound Mode’ toggle button (button 6). Use the LED indication (LED 7) to check what sound mode is currently active.
  • Page 7 KATCH ONE.hex. Insert the USB memory stick into the USB charge connector (connector 1) and execute point 1 – 4 of the factory reset (see 11.1). All the indicator lights (LED 5) turn on, the firmware update sound is played and the DALI KATCH ONE turns off by itself.
  • Page 8 10.0 Cleaning Clean the cabinet with a soft, dry cloth. If the cabinet are dirty, wipe with a soft cloth dipped in all-purpose cleaner and then well wrung out. As this is product contains electronics, be careful not to get it wet, and keep it clear of water.
