MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Katch One and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Dali Katch One

Summary of Contents for Dali Katch One

  • Page 1 MANUAL...

  • Page 2: Table Of Contents

    CONTENTS 1.0 Unpacking ....3 4.0 Volume ..... 9 7.4 Optical In .

  • Page 3: Unpacking

    1.0 UNPACKING Be careful not to damage the contents when unpacking the parts. Check that all parts are included in the cardboard box. Keep the packaging materials in case your speaker needs to be relocated or serviced.

  • Page 4: Button And Led Overview

    2.0 BUTTONS, INDICATION LED’S AND CONNECTIONS 2.1 BUTTON AND BUTTONS Bluetooth select/release/ Volume Down pause/play/skip (See 2.4) LED OVERVIEW Source select (Toggle) Volume Up Power On/Off/Mute Sound Mode (Toggle) LED INDICATION 1 Bluetooth 2 HDMI 3 Optical (for TV) 4 Optical 5 AUX in 6 Volume 7 Sound mode...

  • Page 5: Buttons, Indication Led's And Connections

    2.0 BUTTONS, INDICATION LED’S AND CONNECTIONS USB Power Out/Service 2.2 INPUT/OUTPUT OVERVIEW SUB Out See 7.0 for a detailed description Mains power of all the connectors. AUX In Optical In HDMI In Optical In (TV)

  • Page 6: Remote Control

    2.0 BUTTONS, INDICATION LED’S AND CONNECTIONS 2.3 REMOTE CONTROL 2.4 BLUETOOTH BUTTON FUNCTIONS The Bluetooth button (Button ) and the Mute remote control Bluetooth button can be used to select/release/pause/play/skip to next track. On/Off Sound Mode Select Bluetooth Short press Pause/Play music Short press Skip track forward...

  • Page 7: Power And Auto Source Select

    The DALI KATCH ONE will automatically turn off if no audio has been To turn OFF the DALI KATCH ONE; playing for 20 minutes. If the KATCH ONE is connected to a TV via HDMI 1. Press and hold Power ON/OFF button (Button and CEC is enabled (See 7.6) a power off command from the TV will...

  • Page 8: Auto Source Select

    TV connected to the HDMI is turned on (See 7.6) or if a Bluetooth connected device starts playback. If the DALI KATCH ONE is turned on and no audio is playing, starting playback on a different input will cause the KATCH ONE to automatically switch to the active input.

  • Page 9: Volume

    4.0 VOLUME 4.1 VOLUME DOWN To turn down the volume on the DALI KATCH ONE; 1. Press the Volume Down button on the KATCH ONE (Button ) or on the remote control 4.3 VOLUME INDICATIONS To quickly turn down the volume, press and hold the Volume Down button.

  • Page 10: Bluetooth

    5. When the pairing is complete, the Bluetooth pairing sound is played The DALI KATCH ONE will automatically connect to a device when Bluetooth is selected, if a device has been paired to the KATCH ONE earlier, and is within range. The KATCH ONE will not initiate auto playback. Playback has to be started...

  • Page 11: Bluetooth Release

    5.0 BLUETOOTH 5.3 BLUETOOTH NAMING If you have more than one DALI KATCH ONE, it is possible to change the Bluetooth name of your DALI KATCH ONE. 1. Turn on the DALI KATCH ONE (See 3.1) 5.2 BLUETOOTH RELEASE 2. Press and hold the Power ON/OFF button (Button If you are unable to pair your device to the DALI KATCH ONE;...

  • Page 12: Sound Mode

    6.0 SOUND MODE The DALI KATCH ONE has two sound modes, Focus and Wide. To toggle between the two sound modes press the Sound Mode button (Button The Sound Mode LED (LED 7 ) indicates the selected sound mode. Wide (Default) Expands the sound beyond the KATCH ONE physical dimensions.

  • Page 13: Connections

    7.1 USB POWER OUT / SERVICE 7.2 SUB OUT The USB charge port delivers 5V/1A, which Add a subwoofer to your DALI KATCH ONE makes it possible to charge most devices system for even better bass performance. directly from the DALI KATCH ONE.

  • Page 14: Hdmi In

    Connect a TV to the DALI KATCH ONE using HDMI ARC. If your TV do not support HDMI ARC, DALI recommend using an Optical connection to the DALI KATCH ONE (See 7.5). In this case it is still possible to simultaneously use the HDMI connection to enable the TV remote control for use with the KATCH ONE using the CEC function (See below).

  • Page 15: Positioning

    If placed away from the wall the KATCH ONE’s bass performance will be lowered. To get the best possible audio experience place the DALI KATCH ONE so the front of the KATCH ONE is playing directly towards the primary listening position.

  • Page 16: Factory Reset & Firmware Upgrade

    9.0 FACTORY RESET & FIRMWARE UPGRADE 9.1 FACTORY RESET 9.2 FIRMWARE UPGRADE To reset the DALI KATCH ONE to the factory state; Download the latest firmware from our website and unzip Look for new firmware here: the file to your Windows computer.

  • Page 17: Firmware - Readout Current Version

    9.0 FACTORY RESET & FIRMWARE UPGRADE FLASH 1: EXAMPLE: VERSION 1.1 9.3 FIRMWARE - READOUT Flash 1: Flash 2: Flash 3: CURRENT VERSION First digit(s) First digit(s) Initiate factory reset (See 9.1) to read out current firmware version. SUM = 1 SUM = 1 FLASH 2: The current firmware version is...

  • Page 18: Cleaning

    10.0 CLEANING Clean the cabinet with a soft, dry cloth. If the cabinet are dirty, wipe with a soft cloth dipped in all-purpose cleaner and then well wrung out. As this is product contains electronics, be careful not to get it wet, and keep it clear of water.

  • Page 19: Disposal

    11.0 DISPOSAL If you want to dispose of this product, do not mix it with general household waste. There is a separate collection system for used electronic products in accordance with legislation that requires proper treatment, recovery and recycling. Private households in the EU member states, Switzerland, Liechtenstein and Norway may return their used electronic products free of charge to designated collection facilities or to a retailer (If you purchase a similar new one).
