- Page 1 SCWT14A-WC-Q*1D HALSEY TAYLOR OWNERS MANUAL USES HFC-134A REFRIGERANT 2, 30 - SEE FIG.5 5, 6 3, 4 SEE FIG.4 28, 29 12,13,14,15 FIG. 1 PAGE 1 97321C (7/98)
- Page 2 SCWT14A-WC-Q*1D 97321C (7/98) PAGE 2...
- Page 3 SCWT14A-WC-Q*1D PUSH BUTTON VALVE ADJUSTMENT STREAM HEIGHT ADJUSTMENT SCREW ADJUST THIS SCREW TO ELIMINATE VALVE LEVER "FREE PLAY" OR CONTINUOUS FLOW FROM BUBBLER FIG. 3 1,20,24 FIG. 4 CORRECT STREAM HEIGHT FIG. 5 PAGE 3 97321C (7/98)
-
Page 4: Wiring Diagram
SCWT14A-WC-Q*1D ITEMIZED PARTS LIST WIRING DIAGRAM This drawing is merely for illustrating the components of the electrical system. COLOR RIGHT PANEL LEFT PANEL FRONT PANEL CONDENSER WATER VALVE ADJUSTMENT The condenser water valve is factory preset for a condenser water outlet temperature of 95° to 105° F. If actual temperature varies greatly from this, readjust water flow rate at the valve using the following procedures.
