Texas Instruments TPS54362B EVM User Manual

1 Introduction
The Texas Instruments TPS54362BEVM evaluation module (EVM) helps designers evaluate the operation
and performance of the TPS54362B-Q1 switch-mode power-supply buck regulator. The device is
configurable and can be configured to switch from 200 kHz up to 2.2 MHz. This EVM is optimized for EMI
performance. For the EMI test results, see the application report Passing CISPR25 Radiated Emissions
Using TPS54362B-Q1, SLVA661.
CONVERTER
U1
EVM
TPS54362BEVM
1.1 Performance Summary
The TPS54362BEVM is optimized to meet the CISPR25 EMC standard for automotive components.
TPS54362BEVM was tested at V
reduce emissions to levels deemed acceptable by the previously mentioned standard.
The switching frequency is externally set at a nominal 500 KHz. The compensation components are
external to the integrated circuit (IC) and have been selected to optimize the transient performance of the
device. An external divider allows for an adjustable output voltage.
Table 3 lists a summary of the TPS54362BEVM performance specifications. Specifications are given for
an input voltage of V
TPS54362BEVM is designed and tested for V
measurements, unless otherwise noted.
SPECIFICATION
VIN operating voltage range
Output voltage set-point
Output current range
Operating frequency
SLVUA81 – May 2014
Submit Documentation Feedback
Table 1. Device and Package Configurations
IC
TPS54362BQPWPQ1
Table 2. Input and Output Summary
INPUT VOLTAGE RANGE
V = 3.6 V to 40 V
I
= 12 V an output voltage of 5 V at 2 A. The layout is designed to
(BAT)
= 12 V and an output voltage of 5 V, unless otherwise specified. The
I
Table 3. TPS54362BEVM Performance Specification Summary
TEST CONDITION
V = 7 V to 48 V
I
Copyright © 2014, Texas Instruments Incorporated
TPS54362B EVM User's Guide
PACKAGE
PWP-20
DEFAULT OUTPUT SETTING
5 V at currents up to 3 A
= 6 V to 48 V. The ambient temperature is 25°C for all
I
MIN
6
0
User's Guide
SLVUA81 – May 2014
TYP MAX UNIT
12 48 V
5 V
3 A
500 kHz
TPS54362B EVM User's Guide
1
