Philips PS24FHDCR User Manual

24” fhd color lcd monitor
Hide thumbs
Table of Contents

Advertisement

Quick Links

User Guide
PS24FHDCR
24" FHD Color LCD Monitor

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PS24FHDCR and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Philips PS24FHDCR

Summary of Contents for Philips PS24FHDCR

  • Page 1 User Guide PS24FHDCR 24” FHD Color LCD Monitor...
  • Page 2 Barco NV Beneluxpark 21, 8500 Kortrijk, Belgium Phone: +32 56.23.32.11 Fax: +32 56.26.22.62 Support: www.barco.com/en/support Visit us at the web: www.barco.com Registered address: Barco NV President Kennedypark 35, 8500 Kortrijk, Belgium Phone: +32 56.23.32.11 Fax: +32 56.26.22.62 Support: www.barco.com/en/support Visit us at the web: www.barco.com Printed in Italy...

  • Page 3: Table Of Contents

    Technical specifications ..................36 K5902096 (451920611523) PS24FHDCR 08/03/2018...
  • Page 4 Table of contents K5902096 (451920611523) PS24FHDCR 08/03/2018...

  • Page 5: Welcome

    1. Welcome! 1. WELCOME! Introduction The PS24FHDCR monitor is a 24” color LCD monitor to be used in a system for diagnostic and interven- tional X-ray applications. Type of equipment: movable (on a table) Intended location: outside of patient area (e.g. Control Rooms)

  • Page 6: Product Overview

    Product overview Front Image 1-1 Status LED Up / Brightness increase key Menu / Enter key Down / Brightness decrease key USB-A 2.0 downstream connectors (2x) Rear Image 1-2 Illuminating circle disc Cable cover Monitor stand K5902096 (451920611523) PS24FHDCR 08/03/2018...
  • Page 7 DVI 1 Single Link input (Not used, covered by 100 - 240 VAC mains power input (IEC C14) plastic dust protection) DisplayPort 1.1 input DVI 2 Single Link input +5 VDC, 500 mA power output USB-B 2.0 upstream connector USB-A 2.0 downstream connector K5902096 (451920611523) PS24FHDCR 08/03/2018...
  • Page 8 1. Welcome! K5902096 (451920611523) PS24FHDCR 08/03/2018...

  • Page 9: Monitor Installation

    AWG18 size (according to national Regulation re- quirements regarding maximum admitted cable length). Use the included M4 screw to attach the wire to the protective earth pin. Image 2-2 K5902096 (451920611523) PS24FHDCR 08/03/2018...
  • Page 10 1. Slide the 4 position clips on top of the cable cover in the matching fixation holes at the back of the monitor. 2. Attach the cable cover by pushing the bottom into the monitor until you hear a “click” sound at both ends of the cover. K5902096 (451920611523) PS24FHDCR 08/03/2018...

  • Page 11: Stand Installation By Vesa Interface

    Image 2-6 Stand installation by VESA interface About The PS24FHDCR monitor is provided with a validated stand. If a different stand is needed in the final application, the monitor VESA interface (VESA 100 mm standard) could be used. ARNING If a different stand will be used, it has to be validated in the final application.
  • Page 12 6 mm and that the unthreaded distance to the outer surface of the plastic back cover is 7.8 mm. Image 2-7 K5902096 (451920611523) PS24FHDCR 08/03/2018...

  • Page 13: Daily Operation

    3. Daily operation 3. DAILY OPERATION On/Off switching About The PS24FHDCR monitor automatically turns on as soon as the power cord is connected to the mains plug. The monitor requires at maximum 30 seconds to power-up. Status LED About During start-up, the monitor performs a self-test and sync-test before going into normal operation mode.

  • Page 14: Brightness Adjustment

    When brightness is at 100%, by keeping the Up / Brightness increase key ( ) pressed for at least 3 seconds, the brightness is forced to the MAX brightness mode, which adds up 20 cd/m² to the default stabilized brightness value. Press the Menu / Enter key ( ) to exit the MAX brightness mode. K5902096 (451920611523) PS24FHDCR 08/03/2018...

  • Page 15: Advanced Operation

    4. Advanced operation 4. ADVANCED OPERATION OSD menu structure Below is an overview of the PS24FHDCR OSD menu structure. Detailed info about the different menus and settings is available in the next sections. Info Settings Model: PSXXXHDXR OSD Position Serial Number...

  • Page 16: Monitor Info

    1. Bring up the OSD main menu. 2. Navigate to the Image > Source menu. 3. Select one of the available input image sources. Source DVI2 Info Aspect Ratio Full Screen Color Temperature Calibrated Display Function Native Image Settings Image 4-3 K5902096 (451920611523) PS24FHDCR 08/03/2018...

  • Page 17: Aspect Ratio

    Calibrated: Corresponds to a color temperature of 6800 Kelvin (D68). To select a color temperature 1. Bring up the OSD main menu. 2. Navigate to the Image > Color Temperature menu. 3. Select one of the available color temperature settings. K5902096 (451920611523) PS24FHDCR 08/03/2018...

  • Page 18: Display Function

    LCD and CRT medical monitors. To select a display function 1. Bring up the OSD main menu. 2. Navigate to the Image > Display function menu. 3. Select one of the available display functions. K5902096 (451920611523) PS24FHDCR 08/03/2018...

  • Page 19: Osd Menu Position

    4 minutes (240 sec.) To adjust the OSD menu time-out value 1. Bring up the OSD main menu. 2. Navigate to the Settings > OSD Timeout menu. 3. Select one of the available time-out values. K5902096 (451920611523) PS24FHDCR 08/03/2018...

  • Page 20: Osd Lock

    OSD has been unlocked for about 20 sec. Factory reset About the factory reset The factory reset option allows to reset all OSD menu settings to its default settings. The default settings are described below. Image menu: K5902096 (451920611523) PS24FHDCR 08/03/2018...

  • Page 21: Power Over Dvi

    +5 VDC over DVI. To adjust the power on DVI 1. Bring up the OSD main menu. 2. Navigate to the Settings > DVI1 5V or DVI2 5V menu. 3. Select one of the available options. K5902096 (451920611523) PS24FHDCR 08/03/2018...

  • Page 22: Vdc Power Output

    3. Select On to enable or Off to disable the +5 VDC power output connector. OSD Position Center Info OSD Timeout 240 sec. OSD Lock Factory Reset Image DVI1 5V DVI2 5V Settings 5V Output Back Illumination Image 4-13 K5902096 (451920611523) PS24FHDCR 08/03/2018...

  • Page 23: Back Illumination

    3. Select On to enable or Off to disable the back illumination. OSD Position Center Info OSD Timeout 240 sec. OSD Lock Factory Reset Image DVI1 5V DVI2 5V Settings 5V Output Back Illumination Image 4-14 K5902096 (451920611523) PS24FHDCR 08/03/2018...
  • Page 24 4. Advanced operation K5902096 (451920611523) PS24FHDCR 08/03/2018...

  • Page 25: Cleaning Your Display

    LCD. AUTION Do not apply or spray liquid directly to the display as excess liquid may cause damage to internal electronics. Instead, apply the liquid to a cleaning cloth. K5902096 (451920611523) PS24FHDCR 08/03/2018...
  • Page 26 5. Cleaning your display K5902096 (451920611523) PS24FHDCR 08/03/2018...

  • Page 27: Important Information

    Power requirements: The equipment must be powered by the AC mains voltage. • The equipment is intended for continuous operation. Transient over-voltage To fully disengage the power to the device, please disconnect the power cord from the AC inlet. K5902096 (451920611523) PS24FHDCR 08/03/2018...
  • Page 28 IEC 62471: 2006; EN 62471: 2008 (Photobiological Safety Of Lamps And Lamp System) FCC class B ICES-001 Level B RoHS (2011/65/EC) National Scandinavian Deviations for CL. 1.7.2 Finland: "Laite on liitettävä suojamaadoituskoskettimilla varustettuun pistorasiaan" Norway: "Apparatet må tilkoples jordet stikkontakt" Sweden: "Apparaten skall anslutas till jordat uttag" K5902096 (451920611523) PS24FHDCR 08/03/2018...

  • Page 29: Environmental Information

    “Limit Requirements of toxic substances in Electronic Information Products”. 零件项目(名称) 有毒有害物质或元素 Component name Hazardous substances and elements 铅 镉 汞 六价铬 多溴联苯 多溴二苯 醚 Cr6+ PBDE 印制电路配件 Printed Circuit Assemblies 液晶面板 LCD panel 外接电(线)缆 External Cables 內部线路 Internal wiring 金属外壳 Metal enclosure K5902096 (451920611523) PS24FHDCR 08/03/2018...

  • Page 30: Regulatory Information

    Regulatory information Indications for use The PS24FHDCR is intended to be used as a tool in displaying and viewing digital images (excluding digital mammography) for review and analysis by trained medical practitioners. Caution (USA): Federal law restricts this device to sale by or on the order of a physician. (Details & exemptions are in the Code of Federal Regulations Title 21, 801 Part D).

  • Page 31: Emc Notice

    EMC notice Electromagnetic emissions The PS24FHDCR is intended for use in the electromagnetic environment specified below. The customer or the user of the PS24FHDCR should assure that it is used in such an environment. Emissions test Compliance Electromagnetic environment –...
  • Page 32 Conducted RF RF communications 1. is the a.c. mains voltage prior to application of the test level. 2. PS24FHDCR doesn’t contain susceptible components to magnetic fields. Nevertheless, the PS24FHDCR has been tested up to 30 A/m. K5902096 (451920611523) PS24FHDCR 08/03/2018...
  • Page 33 RF transmitters, an electromagnetic site survey should be considered. If the measured field strength in the location in which the PS24FHDCR is used exceeds the applicable RF compliance level above, the PS24FHDCR should be observed to verify normal operation. If abnormal performance is observed, additional measures may be necessary, such as re-orienting or relocating the PS24FHDCR.

  • Page 34: Explanation Of Symbols

    Recommended separation distance The PS24FHDCR is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled. The customer of the user of the PS24FHDCR can help prevent electromagnetic interfer-...
  • Page 35 Indicates the device is approved according to the BIS regulations Indicates the USB connectors on the device Indicates the DisplayPort connectors on the device Indicates the legal manufacturer Indicates the manufacturing date K5902096 (451920611523) PS24FHDCR 08/03/2018...
  • Page 36 Indicates a device that can be broken or damaged if not handled carefully when being stored. Indicates a device that needs to be protected from moisture when being stored. 7. Values for xx and yy can be found in the technical specifications paragraph. K5902096 (451920611523) PS24FHDCR 08/03/2018...

  • Page 37: Legal Disclaimer

    - graphical, electronic, or mechanical including photocopying, taping or information storage and retrieval systems - without written permission of Barco. © 2018 Barco NV all rights reserved. 8. Values for xx and yy can be found in the technical specifications paragraph. K5902096 (451920611523) PS24FHDCR 08/03/2018...

  • Page 38: Technical Specifications

    Net weight with stand 9.57 ± 0.5 kg Net weight w/o stand 5.69 ± 0.5 kg Net weight packaged with 11.50 ± 0.5 kg stand Tilt +5° / +20° Mounting standard VESA (100 mm) Recommended modalities K5902096 (451920611523) PS24FHDCR 08/03/2018...
  • Page 39 10°C to 40°C (10°C to 35°C within specs) Storage temperature -20°C to 60°C Operating humidity 20% - 80% (non-condensing) Storage humidity 10% - 90% (non-condensing) Operation altitude Up to 3000 m Storage altitude Up to 3000 m K5902096 (451920611523) PS24FHDCR 08/03/2018...
  • Page 40 6. Important information Dimensions 563.5 mm 86.3 mm 525.2 mm Image 6-1 K5902096 (451920611523) PS24FHDCR 08/03/2018...
  • Page 41 6. Important information 168.0 mm 187.9 mm Image 6-2 231.8 mm 100.0 mm Image 6-3 Identification label position The product identification label is located at the back of the monitor under the cable cover as illustrated below. K5902096 (451920611523) PS24FHDCR 08/03/2018...
  • Page 42 6. Important information MAINS USB-B USB-A Image 6-4 K5902096 (451920611523) PS24FHDCR 08/03/2018...
  • Page 46 K5902096-02 (451920611523) March 2018 FIMI S.r.l. Saronno - Italy Barco NV Beneluxpark 21 8500 Kortrijk Belgium Registered address: President Kennedypark 35 8500 Kortrijk Belgium...
