2. Slide the power switch to the "ON" position - the power indicator should turn green.

Cable Connection

1. Connect the Coaxial input port or the Optical input port on the DAC02 to your audio source's output with the
corresponding cable.Use the input selector switch to choose the input type (coaxial or optical) .
Use with Coaxial cable
DVD
Coaxial source (DVD player or TV)
Use with Optical cable
ON/OFF
Volume
ON OFF
USB cable
Coaxial cable
(not included)
Optical
output
USB cable
- +
VOL
Optical Coaxial
AUX Output
Optical Coaxial
AUX Output
