- Page 1 IM3101 12/2019 REV04 ® COOL ARC OPERATOR’S MANUAL ENGLISH Lincoln Electric Bester Sp. z o.o. ul. Jana III Sobieskiego 19A, 58-263 Bielawa, Poland...
-
Page 2: Table Of Contents
12/05 THANKS! For having chosen the QUALITY of the Lincoln Electric products. Please Examine Package and Equipment in case of Damage. Claims for material damaged in shipment must be notified immediately to the dealer. For future reference record in the table below your equipment identification information. Model Name, Code & Serial Number can be found on the machine rating plate. -
Page 3: Index
Technical Specifications NAME INDEX COOL ARC ® K14182-1 INPUT Input Voltage U Input Amperes I 1max 230 V ± 15% 1,5 A COOL ARC ® 400 V ± 15% 440 V ± 15% 0,9A Frequency EMC Class COOL ARC ® 50/60 Hz PARAMETERS RATING The cooling power of flow 1liter per minute at... -
Page 4: Electromagnetic Compatibility (Emc)
Electromagnetic Compatibility (EMC) 11/04 This machine has been designed in accordance with all relevant directives and standards. However, it may still generate electromagnetic disturbances that can affect other systems like telecommunications (telephone, radio, and television) or other safety systems. These disturbances can cause safety problems in the affected systems. Read and understand this section to eliminate or reduce the amount of electromagnetic disturbance generated by this machine. -
Page 5: Safety
Failure to follow the instructions in this manual could cause serious personal injury, loss of life, or damage to this equipment. Read and understand the following explanations of the warning symbols. Lincoln Electric is not responsible for damages caused by improper installation, improper care or abnormal operation. - Page 6 CYLINDER MAY EXPLODE IF DAMAGED: Use only compressed gas cylinders containing the correct shielding gas for the process used and properly operating regulators designed for the gas and pressure used. Always keep cylinders in an upright position securely chained to a fixed support. Do not move or transport gas cylinders with the protection cap removed.
-
Page 7: Introduction
Introduction ® ® COOL ARC 26 cooler is a stand alone recirculating The COOL ARC 26 is delivered empty with no coolant cooling system designed to use with MIG welding power system. FREEZCOOL W000010167 sources that lists the COOL ARC ®... - Page 8 Figure 1 Figure 4 Figure 5 Figure 2 Figure 6 Figure 3 English English...
- Page 9 Figure 7 Figure 8 Figure 9 English English...
-
Page 10: Installation And Operator Instructions
Installation and Operator Instructions Read this entire section before installation or operation Input Supply Connection of the machine. The COOL ARC ® 26 must be supplied by a welding power source in accordance with installation procedure WARNING that can be done only by qualified electrician. Installation must be made in accordance with the appropriate ELECTRIC SHOCK can kill. - Page 11 1. Reservoir for Coolant with Cap: The translucent Circulation of Coolant in the Cooler reservoir enables control of the coolant level. 2. Reservoir filter: 400µm. 3. Minimum and maximum Liquid Level: The minimum recommended liquid level is 3 liters. 4. Quick Connect Coupling: Coolant outlet (supplies cool coolant to the torch/gun).
- Page 12 Advanced User Interface (U7) Configuration Cooler Settings Auto Figure 13 English English...
- Page 13 Standard User Interface (U0) Figure 14 English English...
- Page 14 Advanced User Interface (U7) Filling the reservoir and water lines WARNING Avoid contact with coolant. Wear waterproof gloves and protective eye wear. The cooler should be filled and used only in the vertical position. only recommended coolant FREEZCOOL W000010167 Do not use pre-packaged welding industry coolants. These coolants may contain oil-based substances, Figure 15 which attack the plastic components of the cooler.
- Page 15 Figure 23 Figure 19 Standard User Interface (U0) Figure 24 Figure 25 Figure 20 Figure 26 Figure 27 Figure 28 Figure 21 Figure 29 Figure 30 Figure 22 Figure 31 Figure 32 English English...
- Page 16 After review turn on the power source. Machine will automatically start with filling procedure again. WARNING If the filling procedure fails, contact with the nearest Technical Service Center or Lincoln Electric. Machine ® usage without proper functioning of COOL ARC 26 can cause thermal damage of water torch or COOL ARC ®...
- Page 17 For any repair operations, modifications or maintenance, it welding output. is recommended to contact the nearest Technical Service Center or Lincoln Electric. Repairs and modifications performed by unauthorized service or personnel will 0092 cause the manufacturer’s warranty to become null and void.
- Page 18 Lincoln Electric is not in a position to warrant or guarantee such advice, and assumes no liability, with The frequency of the maintenance operations may vary respect to such information or advice.
- Page 19 WARNING If for any reason you do not understand the test procedures or are unable to perform the tests/repairs safely, contact the nearest authorized Technical Service Center or Lincoln Electric for technical troubleshooting assistance before you proceed. LOCATE PROBLEM POSSIBLE CAUSE RECOMMENDED COURSE OF ACTION (SYMPTOM).
-
Page 20: Weee
12/05 Part List reading instructions Do not use this part list for a machine if its code number is not listed. Contact the Lincoln Electric Service Department for any code number not listed. Use the illustration of assembly page and the table below to determine where the part is located for your particular code machine. -
Page 21: Accessories
Accessories W000010167 FREEZCOOL (coolant) T-5041-003-1R RED HOSE (150 mm) T-5041-004-1R BLUE HOSE (115 mm) D-2218-150-1R BYPASS HOSE (200 mm) English English...
