Environmental Conditions
‣
Operating environment
‣
Temperature: 5 ◦ C to 35 ◦ C (41 ◦ F to 95 ◦ F)
‣
Relative humidity: 20% to 85% noncondensing
‣
Air flow
‣
The chassis fans can produce a maximum of 340 CFM of air flow.
‣
Do not block the ventilation areas at the front and rear of the chassis.
‣
Minimize any restrictions on air flow around the chassis.
Connections
‣
Power:
‣
The RTX Blade Server is powered through ten 1200W power supply units, each
rated at 200-240VAC, 8A, 50/60 Hz. Total system power requirement: 7500W
‣
C19/C20 cables provided for each power supply to connect to a compatible
PDU.
IMPORTANT: Do not use the provided cables with any other product or for
any other purpose.
‣
Switch Management: 10GBASE-T RJ45 connection
Use industry standard CAT6 Ethernet cables for connecting to the network port.
(Cables not included.)
www.nvidia.com
NVIDIA RTX Blade Server
Installation and Setup
DU-09554-001 _v02 | 6
