Summary of Contents for Triton T22i
- Page 1 T22i Shower pump Installation and operating instructions nstallers please note these InstructIons are to be left wIth the user 2180504C February 2009 6479496...
-
Page 2: Table Of Contents
Commissioning ............... 8 Spare parts ..............9 Fault finding ..............10 Guarantee, Service Policy, Etc........Rear cover To check the product suitability for commercial and multiple installations, please contact Triton’s specification advisory service before installation. Telephone: 0844 980 0730... -
Page 3: Plumbing And Electrical Notes
MUST be fitted to both inlet and outlet sides of the pump as an independent means of isolating the water should maintenance or servicing be necessary. Replacement parts can be ordered from Triton Customer Service. See ‘spare parts’ for details. -
Page 4: Introduction
SafETy WarNINGS This book contains all the necessary fitting and In the interest of electrical safety a 30mA operating instructions for your Triton power residual current device (RCD) should be shower pump. Please read them carefully. installed in all uK electric and pumped Care taken during the installation will provide a shower circuits. -
Page 5: Key To Main Components
Shower pump Fig. KEy TO maIN COmPONENTS (fig.1) 1. Pump 2. Connector hose X4 3. Inlet filter washer X2 4. Rubber washer X2... -
Page 6: Water Requirements
Shower pump WaTEr rEqUIrEmENTS Stopvalve Cold water Cold supply cistern Gate 1 metre head valve Cold water Hot supply mains supply Riser Mixer valve rail Hot water Essex cylinder flange Service Service valves valves Drain valve Pump Other draw-offs Isolating switch or pull cord switch (both fused at 5A) Ring main... -
Page 7: Electrical Requirements
This may In situations where this cannot be met, contact be part of the consumer unit or a separate unit. Triton Customer Service for advice. If used with note: The installation MUST comply with a combination cylinder, the cold water cistern current IEE regulations. -
Page 8: Siting Of The Pump
Shower pump SITING Of THE PUmP INSTallaTION warnInG! warnInG! ThE unIT musT noT BE posITIonED Installation of the pump will break whErE IT wILL BE suBJECT To the earth continuity of the pipework FrEEZInG ConDITIons. installation. It is important that the earth be restored by cross bonding the pipework, to conform with current IEE The pump MUST ALWAYS be positioned... - Page 9 Shower pump Procedure Fig. Turn off mains water and electrical supplies. Drain the cold water cistern and hot water cylinder and make a suitable connection to the hot water supply. Position the pump horizontally (with the ports in the upright position) with the feet on a solid base so that it will not transmit vibration.
-
Page 10: Commissioning
Shower pump COmmISSIONING note: If care has been taken to prevent any obvious debris entering the system, the above Before the first operation of the shower pump, it procedure should be adequate for normal is necessary to flush out any system debris from operating conditions of the pump and shower. -
Page 11: Spare Parts
Shower pump SParE ParTS Description Part No. Pump assembly T22IOOM Hose assembly X1 83309460 Filter/seal pack X2 of each 83309470... -
Page 12: Fault Finding
1.4.2 Check head of water. 1.4.3 Make sure the inlet filter is clean. 1.5 Failed pump motor. 1.5.1 Replace the pump unit. Contact Triton Customer Service. 2 Poor or no 2.1 Pump motor not 2.1.1 See causes 1.1, 1.2, 1.3, 1.4, 1.5, and 1.6. - Page 13 Shower pump...
- Page 14 Shower pump...
- Page 15 Shower pump ecycling equiRements To ensure that local and national legislation is complied with, Triton plc ask that you dispose of any obsolete product in an environmentally friendly manner. Do not place obsolete products in a wheelie bin.
- Page 16 Warwickshire CV11 4NR www.tritonshowers.co.uk Triton is a division of Norcros Group (Holdings) Limited e-mail: serviceenquiries@tritonshowers.co.uk Extended Warranty AVAILABLE NOW. Call 0844 980 0740 for more details. TRITON reserve the right to change product specification without prior notice. E&OA. © TRITON SHOWERS 2009...
