- Page 1 ® SX4D GSM HONECELL ESKTOP HONE 900 MH OICE ODEL 1800 MH OICE ODEL ANUAL Digital call clarity and privacy at your fingertips 03/09/01 Part No. 56020401...
-
Page 2: Desktop Phone
® SX4D GSM HONECELL ESKTOP HONE 900 MH OICE ODEL 1800 MH OICE ODEL ANUAL... -
Page 3: Introduction
Please follow this guide to unpack, set up and operate your new Phonecell ® SX4D GSM Desktop Phone safely and properly. Telular is proud to welcome you as a valued customer. Your satisfaction is our most important concern. Telular Corporation Corporate Headquarters... -
Page 4: Table Of Contents
Step 1. Antenna Setup... 11 Antenna Setup ...11 Antenna Tips ...11 Step 2. Connect Phonecell SX4D to AC Power ... 12 Step 3. SIM Card Installation and Setup ... 13 SIM PIN Programming ... 14 Step 4. Determine Phonecell SX4D Location ... 16 Step 5. -
Page 5: Safety Information
Safe Operation Requirement Do not operate your Phonecell SX4D when any person is within 1 inch (2,5 cm) of the antenna. Temperature Environment Operating Temperature From -10°C (14°F) to +50°C (122°F);... - Page 6 FCC regulations prohibit using your cellular device while the plane is in the air. Children Do not allow children to play with your Phonecell SX4D to prevent damage to the unit. Blasting Areas Construction crews often use remote control RF devices to set off explosives.
- Page 7 MA 02269, Attn: Publications Sales Division. FCC Part 15 Class B Compliance The Phonecell SX4D GSM 900 and GSM 1800 models have been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules.
-
Page 8: Important Notices
TERMS AND CONDITIONS FOR USE OF PHONECELL® PRODUCTS ("Product") These Terms and Conditions are a legal contract between you and Telular Corporation for the title to and use of the Product. BY RETAINING AND USING THE PRODUCT AFTER RECEIPT OF IT, YOU AGREE TO THE TERMS AND CONDITIONS INCLUDING WARRANTY DISCLAIMERS, LIMITATIONS OF LIABILITY AND INDEMNIFICA- TION PROVISIONS BELOW. - Page 9 Laws in the United States and other countries preserve for Telular certain exclusive rights for copyrighted Telular software such as the exclusive rights to reproduce in copies and distribute copies of such Telular software. Telular software may be copied into, used in and redistributed with only the Product associated with such Telular software.
-
Page 10: Getting Started
Getting Started... Un-Packing Your Phonecell SX4D The Phonecell SX4D GSM 900 and SX4D GSM 1800 come with the following: Phonecell SX4D Desktop Phone Antenna 6 VDC Power Supply (AC-to-DC) Carefully remove the unit from the shipping carton and check for evidence of shipping damage. -
Page 11: Installation Summary
Installation Summary The following steps summarize the installation of the Phonecell SX4D. These steps are explained in detail in the remainder of this manual. Step 1. Antenna Setup (page 11) Connect the antenna. Finger-tighten the antenna; do not overtighten. WARNING! -
Page 12: Step 1. Antenna Setup
Step 1. Antenna Setup The Phonecell SX4D comes with an antenna. However, your coverage area may require a higher-gain antenna for optimal call clarity and performance. The Phonecell SX4D is compatible with a variety of antenna options, including magnetic-mount and Yagi models –... -
Page 13: Step 2. Connect Phonecell Sx4D To Ac Power
Step 2. Connect Phonecell SX4D to AC Power 1) Connect the DC barrel connector of the 6 VDC Power Supply to the rear panel receptacle of the Phonecell SX4D - see Figure 3. WARNING! Never operate your Phonecell SX4D when any person is within 1 inch (2,5 cm) of the antenna. -
Page 14: Step 3. Sim Card Installation And Setup
Step 3. SIM Card Installation and Setup IMPORTANT! If your Phonecell SX4D did NOT come with a pre-installed mini-SIM (Subscriber Identity Module) card, OR if you’re experiencing SIM card-related problems, fol- low the steps below. Otherwise, continue with STEP 5. -
Page 15: Sim Pin Programming
PIN entry feature, the PIN must be correctly programmed and automatic PIN entry must be enabled. If PIN entry is requested while automatic PIN entry is disabled, the Phonecell SX4D emits a non-registered service tone. The SIM PIN can be manually entered at that time: Press: <4-digit SIM number> # If entry is successful, the non-registered service tone will be replaced by service dial tone. - Page 16 NOTE: This procedure will change the PIN encoded on the SIM. It will not change the PIN stored in the Phonecell SX4D for automatic entry of the PIN when request- ed by the GSM module. (See previous page for instructions on how to enter the auto- entry PIN value).
-
Page 17: Step 4. Determine Phonecell Sx4D Location
The Phonecell SX4D will usually be placed on a desk or table, but may be hung on a wall if that is more convenient for the user. For best results, the unit should be mounted near a window or on an exterior wall - see Figure 7 and Figure 8. -
Page 18: Step 5. Wall-Mount Installation
Step 5. Optional Wall-Mount Installation Your Phonecell SX4D may be mounted on a wall. Be sure to test call quality in the selected location before you permanently mount the Phonecell SX4D to the wall. Pre-Installation Tips: Make sure the location is dry, away from overhead water pipes, and protected from weather conditions. -
Page 19: Phonecell Sx4D Operation
Phonecell SX4D Operation Once your Phonecell SX4D is installed, it is ready for operation. LCD Display The Phonecell SX4D’s LCD displays three rows of information: Legends, Dialed Digits and Alpha - see Figure 13. Legends The top row consists of the following legends and icons: •... -
Page 20: Phonecell Sx4D Power Mode
Phonecell SX4D Operation - continued Phonecell SX4D Normal Power Mode When the Phonecell SX4D is powered on, the unit automat- ically proceeds through the following steps: Time Elapsed LCD Display 16 seconds "Initializing" 2 seconds All LCD fields illuminated 2 seconds... - Page 21 • The hash (#) key displays " " NOTE: When the handset is on-hook and keys are pressed, numeric digits are dis- played only when the Phonecell SX4D is in the programming mode. Dialed digits move from right to left as they are entered.
- Page 22 In-Use Indicator The In-Use Indicator displays a “U” in the 14th character position when the Phonecell SX4D is in use (i.e. call data is sent to the cellular base station). The 14th character remains blank when the Phonecell SX4D is not in use.
-
Page 23: Phonecell Sx4D Controls
Phonecell Operation - continued Phonecell SX4D Controls Front Panel All controls for the Phonecell SX4D are located on the front panel - see Figure 16. Pressing any of the front panel controls will cause the unit to beep for approxi- mately 100 milliseconds when the key is depressed. -
Page 24: How To Place A Call
“N” is displayed on the LCD in the Alpha (bottom) row. Hang-up the Phonecell SX4D and try again. If the No-Service tone continues and the “N” continues to be displayed, contact your service provider to make sure cellu- lar service is activated.). -
Page 25: Variable Dial Time (Auto Send Delay) Option
– without the 3-second Auto SEND Delay. The Phonecell SX4D stores a list of up to 50 different numbers in its memory. This list contains the last 50 numbers that have been called at least twice successfully. - Page 26 "subscriber busy" to another direc- tory number. Register: Erase: # # 67 Activate: Deactivate: # 67 SX4D GSM 900 • SX4D GSM 1800 Ph No Teleservice # <Send> Ph No Teleservice # <Send> Teleservice # <Send> Teleservice # <Send>...
- Page 27 If subscribed to in temporary mode with default value “presentation not restricted,” the user may invoke CLIR, for the specific call only: Register: # 31 # Call Phone Number <Send> SX4D GSM 900 • SX4D GSM 1800 Ph No Teleservice Delay # <Send>...
- Page 28 Deactivate: # 330 All Outgoing Call Barring: On activation all outgoing calls is barred; on deactivation all outgoing call barring is disabled. Activate: Deactivate: # 333 SX4D GSM 900 SX4D GSM 1800 · Password TeleService # <Send> Password TeleService # <Send>...
- Page 29 “any characters defined in GSM 03.08 Default Alphabet” # <Send> “1 or 2 characters defined in GSM 03.08 Default Alphabet” # <Send> SX4D GSM 900 • SX4D GSM 1800 Password TeleService # <Send>...
-
Page 30: Phonecell Sx4D Troubleshooting
Upon loss of power to the Phonecell SX4D, verify proper connection to AC. If AC power is unavailable, verify that the batteries are in good condition and that the battery switch is in the battery power active position. -
Page 31: Phonecell Sx4D Programming
Phonecell SX4D Programming Phonecell SX4D Programming Mode Overview The Phonecell SX4D has several programmable options for unique customer or network applications. These options are stored in the Phonecell SX4D’s non- volatile memory and are retained during power cycling. Programming Mode The Phonecell SX4D’s non-volatile memory can be accessed in the Programming... -
Page 32: Phonecell Sx4D User-Programming Commands
The following key sequence is used to enter the Zero Delay Dial option: Label: ZERO-DELAY DIAL Data: <zero-delay dial> The zero delay dial value is set to 0 for Disable and 1 for Enable. The factory default is 1 (Enable). SX4D GSM 900 • SX4D GSM 1800 ANUAL... -
Page 33: Phonecell Sx4D Technician-Programming Commands
The following commands are to used by trained field technicians to set up the Phonecell SX4D for operation in the network. Since these commands can directly affect the proper operation of the unit, there is an additional level of security to prevent casual access. - Page 34 MEP operation value is not in the range 0 to 3, it is considered invalid. The MEP password is a special value available only to authorized personnel. The factory default is set to 0 deactivated. SX4D GSM 900 • SX4D GSM 1800 <MEP Password> <MEP Password>...
- Page 35 This command will accept the digits 0 through 9. If the Voicemail Retrieval Digit String is less than 3 characters or more than 10 characters, it is considered invalid and the Phonecell SX4D will not update or store this value; the currently stored value will remain. The factory default is unprogrammed.
- Page 36 ©2001 TELULAR CORPORATION Part No. 56020401...
