- Page 1 SX4P ® HONECELL CDMA 2000 1 Fixed Wireless Phone ANUAL 6/13/03 Part Number 56027602...
- Page 2 SX4P MENU STRUCTURE Menu Phonecell SX4P 1x ® SMS Menu Create Message Read Message Delete Message Speed Dial Save Recall Data Mode Settings Call Alert Volume Msg Alert Volume Voice Mail Number Call Alert Tone Auto Send Delay LCD Contrast Zero-Delay Dial Voice Prv Voice Prv Alert...
-
Page 3: Contents
TERMS AND CONDITIONS FOR USE OF PHONECELL These Terms and Conditions are a legal contract between you and Telular Corporation for the title to and use of the Product. BY RETAINING AND USING THE PRODUCT AFTER RECEIPT OF IT, YOU AGREE TO THE TERMS AND CONDITIONS INCLUDING WARRANTY DISCLAIMERS, LIMITATIONS OF LIABILITY AND INDEMNIFICATION PROVISIONS BELOW. -
Page 4: Table Of Contents
TABLE OF CONTENTS SX4P Menu Structure...ii Contents ...iii Safe Operation Instructions ...iii Important Notices...iii SX4P Setup...1 Emergency Batteries ...1 Location and Setup...1 Connect the Handset ...2 Wall-Mounting ...2 Connect the SX4P to AC Power ...3 SX4P Basics ...4 Function Keys ...4 LCD Screen Icons...4 Service Indication ...5 Making Calls ...5... -
Page 5: Sx4P Setup
SX4P SETUP Emergency Batteries Install Batteries 1. Remove the battery access door screw that is located on the bottom of the unit - see Figure 1. 2. Press the battery access door tab and remove the battery access door. 3. Install 6 “AAA” alkaline batteries (not supplied). Battery Access Door Battery Access... -
Page 6: Connect The Handset
Before the SX4P can be operated, the handset cable must be connected - see Figure 5. 1. Connect one end of the handset cable to the phone jack. 2. Connect the other end of the handset cable to the handset. Handset cable Figure 5 - SX4P handset connection. -
Page 7: Connect The Sx4P To Ac Power
1. Attach the barrel connector of the power supply to the AC power input on the rear panel of the SX4P. 2. Connect the AC power cord to the power supply. 3. Move the AC/Battery switch to the AC position. 4. -
Page 8: Sx4P Basics
SX4P BASICS Function Keys The keypad includes all digits 0 through 9 and special characters hash/pound (#) and star/asterisk (*). All data entry and programming activities are performed using the keypad. Redial/Hands-Free key - Provides redial capability and hands-free dialing. NOTE: The SX4P is not a speakerphone. -
Page 9: Service Indication
When it is powered on, the SX4P will display “Initializing” while it sets up, then it will display your phone number followed by the hardware and software versions. If service is available, “Telular SX4 1x” will display when the setup is complete. If the unit is roaming, an “R”... -
Page 10: Features
FEATURES Use the Voicemail Key (envelope ICON) to navigate up and down the menu tree. Use the Redial Key to cancel an entry. When finished with parameter changes, press the Voicemail Key to pro- gram the changes to the phone. Alternatively, lifting the handset from the cradle and replacing it will also program the changes to the phone. - Page 11 You can delete messages from the Read Messages menu or the Delete Messages menu. The Read Messages menu allows deletion of specific messages while the Delete Messages menu allows deletion of groups of message types. Deleting Messages from the Read Message Menu 1.
-
Page 12: Data Features
Data Connectivity Kit A special data kit must be used to allow data connectivity to the SX4P. For more information on this kit, contact your service provider or nearest Telular dealer. Voicemail Set Voicemail Access Number 1. Press the FLASH key, then select Settings. -
Page 13: Speed Dial
Store a Number 1. Press the FLASH key, then select Speed Dial. 2. Select Save. 3. Enter the phone number to be stored, then press the FLASH key. 4. Enter the speed dial location (0-9, *, or #). 5. Press the FLASH key. View the Speed Dial List 1. -
Page 14: Settings
SETTINGS Use the Voicemail Key (envelope ICON) to navigate up and down the menu tree. Use the Redial Key to cancel an entry. When finished with parameter changes, press the Voicemail Key to pro- gram the changes to the phone. Alternatively, lifting the handset from the cradle and replacing it will also program the changes to the phone. -
Page 15: View Phone Number
2. Select Zero Dial Delay. 3. Enter the desired setting. 0 = Off 1 = On (default) 4. Press the FLASH key. View Phone Number 1 Press the FLASH key, then select Settings. 2. Select MIN. The phone number of the unit will display. Voice Privacy This option allows additional security via encryption on the voice channel. -
Page 16: Sx4P Troubleshooting
SX4P TROUBLESHOOTING Unable to Send/Receive Data/FAX Calls Check all the connections from the SX4P to other equipment (computer, fax machine, etc.). Verify that necessary settings have been properly configured (see the Data Features section of this manual). If everything is properly connected and configured and you are still unable to send or receive data or fax calls, contact your service provider. -
Page 17: General Information And Safety
Standard. The design of your Telular Phonecell SX4P complies with this updated Standard. If you want to limit RF exposure even further than the updated ANSI Standard, you may choose to control the duration of your calls and operate your phone in the most power-efficient manner. -
Page 18: Warranty
(15) months from date of shipment from Telular. Telular, at its option, shall at no charge either repair, replace or refund the purchase price of the Product during the warranty period, provided it is returned by Buyer in accordance with the terms of this warranty to the Telular designated repair center. -
Page 19: General Provisions
LONG AN IMPLIED WARRANTY LASTS. VI. SOFTWARE PROVISIONS: Laws in the United States and other countries preserve for Telular certain exclusive rights for copyrighted Telular software such as the exclusive rights to reproduce in copies and distribute copies of such Telular software. Telular software may be copied into, used in and redistributed with only the Product associated with such Telular software. -
Page 20: Appendix A: How To Setup Pc Serial Ports For Phonecell Digital Fax/Data
APPENDIX A: HOW TO SETUP PC SERIAL PORTS FOR PHONECELL DIGITAL FAX/DATA Requirements · CDMA account with your network service provider including a Data/Fax facility. · PC/Laptop/ Notebook with Com Port. · Windows 95/98 · · RS-232 Cable (DB9 to DB15). NOTE: When all of the above have been satisfied, you may proceed. - Page 21 4) Select ‘Standard 19200 bps Modem’ and click on ‘Properties’.. 5) Select ‘Communication’ Port (COM1) and Maximum speed of 115,200 bps. Phonecell SX4P 1x User Manual ®...
- Page 22 then click ‘Advanced’. 7) Check the box for ‘Use Control Flow’ and then click on ‘Hardware (RTS/CTS) and then select ‘OK’. Phonecell SX4P 1x ® User Manual...
- Page 23 8) Click on ‘OK’ 9) Click on ‘Close’. Phonecell SX4P 1x User Manual ®...
- Page 24 10) Run ‘Dial-up Networking’. Double click the icon ‘Make New Connection’. 11) Type “Telular 1xRTT on the first entry field; select the ‘Standard 19200 modem’ and click on ‘Next’. Phonecell SX4P 1x User Manual ®...
- Page 25 12) Type the network provider’s phone number (#777) and click on ‘Next’ and then click on ‘Finish’. 13) Right click on the new icon ‘Telular 1xRTT’ and left click on ‘Properties’. Phonecell SX4P 1x User Manual ®...
- Page 26 14) Click on ‘Server Types’ (DO NOT check the ‘Use Area Code and Dialing Properties). 15) Check the ‘TCP/IP’ box and click on ‘TCP/IP Settings’. Phonecell SX4P 1x User Manual ®...
- Page 27 17) To connect to the Internet you will need to double click on the new profile just created called (Telular 1XRTT) now resident in the ‘Dial-Up Networking’ window. After double clicking on the new profile icon you need to enter your user name and password and click on ‘Connect”.
- Page 28 647 North Lakeview Parkway Vernon Hills, Illinois 60061, USA Tel: 847-247-9400 • Fax: 847-247-0021 E-mail: support@telular.com http://www.telular.com ©2003 Telular Corporation, all rights reserved. Part Number 56027602...
