ABSCO SHEDS 3030RS-PTX Instruction Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
AU: 1800 029 701
N Z: 0800 466 444
We thank you for choosing an Australian Made Shed. For further assistance please
visit our detailed instructional video library at
At ABSCO Industries we are always looking to be number ONE, so please let us
know what you think of our instructions. Feedback makes us better.
feedback@absco.com.au
ABSCO INDUSTRIES
MANU FA CT URED
IN A US TR ALIA
SNAPTiTE
Assemb ly
Absco Industries
ABSCO RURAL SHED
MODEL: 3030RS-PTX
9' 9 5/16" W x 9' 9 5/16" D x 8' 7/16" H
admin@absco.com.au
www.abscosheds.com.au
www.abscosheds.com.au/USA
ASSEMBLY INSTRUCTION - MODEL: J30302G 26/02/14
Assembly Instruction Manual
WHEN LAYING YOUR CONCRETE
SLAB, ENSURE THERE IS A REBATED
EDGE 1" DEEP AROUND THE PERIMETER
CHANNEL
REBATED EDGE
CONCRETE SLAB
Download the Absco
Sheds Assembly App
for instructional videos
Model: 3030RS-PTX
SIDE: 9' 10 7⁄64"
HEIGHT: 6' 10 43⁄64"
THIS WILL HELP
WATER EGRESS FROM
THE BASE OF THE SHED
3" WIDE
REBATE
19/07/2019
1.10
PAGE 1
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the 3030RS-PTX and is the answer not in the manual?

Questions and answers

Related Manuals for ABSCO SHEDS 3030RS-PTX

Summary of Contents for ABSCO SHEDS 3030RS-PTX

  • Page 1 SIDE: 9' 10 7⁄64" HEIGHT: 6' 10 43⁄64" ABSCO RURAL SHED MODEL: 3030RS-PTX 9’ 9 5/16” W x 9’ 9 5/16” D x 8’ 7/16” H AU: 1800 029 701 admin@absco.com.au N Z: 0800 466 444 www.abscosheds.com.au WHEN LAYING YOUR CONCRETE SLAB, ENSURE THERE IS A REBATED EDGE 1"...
  • Page 2 ABSCO RURAL SHED MODEL: 3030RS-PTX 9’ 9 5/16” W x 9’ 9 5/16” D x 8’ 7/16” H GENERAL INSTRUCTIONS • Before commencing any assembly, read through these instructions in detail to gain a thorough understanding of assembly methods and associated details.
  • Page 3 ABSCO RURAL SHED MODEL: 3030RS-PTX 9’ 9 5/16” W x 9’ 9 5/16” D x 8’ 7/16” H COMPONENT PACKING LIST Check off all components. SHEET PACK- 3030RSSP COMPONENT PART COMPONENT PART CHK QTY DESCRIPTION DESCRIPTION STEEL SHEET STEEL SHEET 158S 5’...
  • Page 4 ABSCO RURAL SHED MODEL: 3030RS-PTX 9’ 9 5/16” W x 9’ 9 5/16” D x 8’ 7/16” H COMPONENT PACKING LIST Check off all components. FRAME PACK - 3030RSFP COMPONENT PART COMPONENT PART CHK QTY DESCRIPTION DESCRIPTION FRAME FRAME C2946...
  • Page 5 ABSCO RURAL SHED MODEL: 3030RS-PTX 9’ 9 5/16” W x 9’ 9 5/16” D x 8’ 7/16” H Frame Section Identification Guide There are several types of frame section, each featuring a different combination of notches and/or holes. Frame sections are coded with a letter representing the type of frame section, followed by the length of the frame section in millimeters.
  • Page 6 (EG. Pozi drive) increases the risk of stripping the head of these screws. Some holes are pre-punched in Absco sheds’ frame sections, however the wide range of positions that most fasteners are required for means that the...
  • Page 7 ABSCO RURAL SHED MODEL: 3030RS-PTX 9’ 9 5/16” W x 9’ 9 5/16” D x 8’ 7/16” H Overview Of Internal Frame Absco Industries Assembly Instruction Manual Model: 3030RS-PTX 19/07/2019 1.10...
  • Page 8 ABSCO RURAL SHED MODEL: 3030RS-PTX 9’ 9 5/16” W x 9’ 9 5/16” D x 8’ 7/16” H Side Wall Frame Assembly BKT11 2 required. J2315 M1490 C2295 Boxed C2060 ZACO200 K1465 C2060 BOXED SECTIONS BKT17 C2295 C0100 C2060 J2315...

  • Page 9: Rear Frame Assembly

    ABSCO RURAL SHED MODEL: 3030RS-PTX 9’ 9 5/16” W x 9’ 9 5/16” D x 8’ 7/16” H Rear Frame Assembly 1 required. 2x C2060 Boxed K1415 BOXED SECTION BKT17 C2020 C2020 Absco Industries Assembly Instruction Manual Model: 3030RS-PTX 19/07/2019...
  • Page 10 ABSCO RURAL SHED MODEL: 3030RS-PTX 9’ 9 5/16” W x 9’ 9 5/16” D x 8’ 7/16” H Prepare Edge Beam Assemble the Outer beam and Inner beams on the Outer edge Inner edge ground first using wafer head tek screws (FAST014) at 5...
  • Page 11 ABSCO RURAL SHED MODEL: 3030RS-PTX 9’ 9 5/16” W x 9’ 9 5/16” D x 8’ 7/16” H Wall Frame Assembly NOTE: During frame construction the structure will be unstable until Stand both side walls and join with complete. Consider using bracing, rear frame then the edge beam.
  • Page 12 ABSCO RURAL SHED MODEL: 3030RS-PTX 9’ 9 5/16” W x 9’ 9 5/16” D x 8’ 7/16” H Purlin Assembly Fasten purlins to the purlin brackets. Six purlins are placed on the high side of each INTERNAL VIEW OF REAR STUD purlin bracket.
  • Page 13 ABSCO RURAL SHED MODEL: 3030RS-PTX 9’ 9 5/16” W x 9’ 9 5/16” D x 8’ 7/16” H Anchoring NOTE: • For installation next to buildings, fences or other obstacles, the side walls or rear wall may best be cladded before anchoring.
  • Page 14 ABSCO RURAL SHED MODEL: 3030RS-PTX 9’ 9 5/16” W x 9’ 9 5/16” D x 8’ 7/16” H Roof Sheet Cladding Mark a centre line along the purlins, place the first sheet (158S) on the roof frame and align the centre of the edge rib of the sheet.
  • Page 15 ABSCO RURAL SHED MODEL: 3030RS-PTX 9’ 9 5/16” W x 9’ 9 5/16” D x 8’ 7/16” H Wall Sheet Cladding Rear wall is 4x 214 sheet 2270R 2400R TR19 2400L Repeat the process described for the roof 2270L sheeting cladding for the side wall and back wall.
  • Page 16 ABSCO RURAL SHED MODEL: 3030RS-PTX 9’ 9 5/16” W x 9’ 9 5/16” D x 8’ 7/16” H Gutter Installation FAST009 Place the TR25 gutter end caps on each end of the TR22 gutter. Drill 1x 1/8” hole through the front, back and underside of where the TR25 overlaps the TR22, and fit 1x FAST009, Pop Rivet into each hole.
  • Page 17 ABSCO RURAL SHED MODEL: 3030RS-PTX 9’ 9 5/16” W x 9’ 9 5/16” D x 8’ 7/16” H Gutter Installation Mount the TR22 gutter onto the RWG06 gutter brackets ensuring that all loops on the RWG06 gutter brackets interlock into RWG06 the loop of the gutter profile.

  • Page 18: Trim Installation

    ABSCO RURAL SHED MODEL: 3030RS-PTX 9’ 9 5/16” W x 9’ 9 5/16” D x 8’ 7/16” H Trim Installation TR06 TR08 TR06 Fit barge capping to gable end walls, fixing through the roof at purlin locations. Lay the ridge capping centrally on the roof, overlapping the sections to attain the required length equivalent to the roof sheeting, and fix to every second rib of the roof sheeting with screws and neo washers.
  • Page 19 ABSCO RURAL SHED MODEL: 3030RS-PTX 9’ 9 5/16” W x 9’ 9 5/16” D x 8’ 7/16” H Clean Up & Troubleshooting • Photograph the completed assembly for future reference • Reduce the risk of corrosion by hosing or blowing the completed structure to remove metal shavings, particularly those from on top of painted surfaces •...
  • Page 20 Absco Sheds Storage Guidelines • Absco Sheds are designed to be weatherproof for normal weather conditions. In the event of extreme weather conditions such as heavy rain, combined with high wind gusts, the ridge capping, sheeting joins, screw fi xings etc., may exhibit minor deformations which may allow some water entry. These areas should be checked regularly to ensure that maximum strength and protection is maintained.

  • Page 21: Against Defects

    THE CUSTOMER SERVICE MANAGER, ABSCO SHEDS, PO BOX 119 ACACIA RIDGE QLD AUSTRALIA 4110 PHONE: +61 1800 029701 EMAIL: warranty@absco.com.au...
