COUGAR Phontum Pro User Manual

w ww . c ou gar ga m in g. com

PRODUCT PARTS AND PACKAGE CONTENTS

Steel-based minimalist headband design
A
Extra-large memory foam ear pad
B
Detachable microphone for gaming
C
Noise cancellation Sensor, Volume & Mute Control
D
Adapter
E
USB Type-A connector
F
3.5mm 4-pole connector
G
G
F

INSTRUCTIONS

Interchangeable Ear Pads : Extra-large memory foam ear pad
A
Interchangeable Ear Pads : On-the-go breathable ear pad
B
How to adjust the microphone
C
The sign toward your mouth
can receive the the best
sound quality.
REAL GEAR FOR REAL GAMERS
3.5mm 4-pole
USB Type-A
E
Please do not cover the sensor and keep at least 25cm-distance from main microphone.
R
R
PHONTUM
B
D

SPECIFICATIONS

HEADPHONES
Drivers 53mm
20Hz - 20KHz
Frequency response
Sensitivity at 1KHz 98dB ± 3dB
Impedance at 1KHz 32ohm +/- 15%
Cable Length 1.3m
The above specifications may vary by country or region

PACKAGE CONTAINS

COUGAR PHONTUM PRO Gaming Headset
Detachable Microphone
Interchangeable Ear Pads

HARDWARE REQUIREMENTS

SINGLE PLUG DEVICES
Audio: 3.5 mm audio plug.
●
Audio + Microphone: 3.5 mm audio + microphone integrated plug.
●
USB Port DEVICES Audio + Microphone: USB Type A Port
Dual USB Port Devices (for usage with the audio/mic splitter adapter)
●
Audio + Microphone: USB Type A Port
PRO
A
B
C
L
L
MICROPHONE
9.7mm
Type
Noise Cancelling
Frequency 100Hz to 10KHz
Sensitivity at 1KHz -47dB ± 3dB
Impedance 2.2k
Detachable Control Unit
User Manual
