Schleibinger CDF Manual

Freeze-thaw testing equipment
Hide thumbs Also See for CDF:
Table of Contents

Advertisement

Quick Links

Download this manual
Schleibinger CDF/CIF - Freeze-Thaw Testing Equipment
Schleibinger Geräte
Teubert u. Greim GmbH
Gewerbestraße 4
84428 Buchbach
Germany
Tel. +49 8086 9473110
Fax. +49 8086 9473114
www.schleibinger.com
info@schleibinger.com
August 29, 2019
REV02

Advertisement

Table of Contents
loading

Related Manuals for Schleibinger CDF

Summary of Contents for Schleibinger CDF

  • Page 1 Schleibinger CDF/CIF - Freeze-Thaw Testing Equipment Schleibinger Geräte Teubert u. Greim GmbH Gewerbestraße 4 84428 Buchbach Germany Tel. +49 8086 9473110 Fax. +49 8086 9473114 www.schleibinger.com info@schleibinger.com August 29, 2019 REV02...

  • Page 2: Table Of Contents

    3 Installation 3.1 Set up of the CDF test equipmpent ... . . 3.2 Configuration of the Network access ... .

  • Page 3: Contents

    Contents 6 Software handling with web browser 6.1 Measured Values ..... . . 6.2 Data ......6.3 Profile .

  • Page 4: Introduction

    1 Introduction 1 Introduction We congratulate you on the purchase of the CDF test equipment. With this equipment, you have acquired a high-quality test device for the real- ization of the freeze-thaw resistance test. Equipped with a microprocessor- controlled controller with internet interface, the device complies with the state of technology and thus meets the requirements of the future.

  • Page 5: Safety Instructions

    0. There are no special requirements for environmental or water protection for cooling liquid. Until 2017, the CDF machines were built with the refrigerant R507. Since 2017 the Schleibinger CDF machines are being built with the refrigerant R448a.

  • Page 6: Personal Safety

    • Pentration into soil, water and sewage system is to be avoided. 2.3.1 Protectives and behavioral rules • Do not leave the lid of the CDF machine open. • Cover not used place in the CDF bath with some cover plates or dummy containers. • Wear eye/face protection.

  • Page 7: Reaction To Malfunctions

    2 Safety instructions • Avoid breathing vapors. • Avoid contact with eyes, skin and clothing. • Immediately remove product residues from the skin, gently clean the skin and dry thoroughly. 2.3.2 Reaction to malfunctions • In the case of safety-endangering defects and malfunctions, do not use the device and inform those responisible.

  • Page 8: Installation

    For the set up of the CDF equipment, please ensure free air circulation around the equipment (2). The CDF machine should be set up to be level. Please check this by a level at the testing bath (3). If necessary, the device can be leveled with four adjustable feets.

  • Page 9: Configuration Of The Network Access

    3 Installation 3.2 Configuration of the Network access The Schleibinger data logger, the Slabtester and the CDF machine are equipped with a 100 BaseT network interface. It can be integrated within a local Intranet or globally into the Internet. The network configuration...

  • Page 10: Accessing The Data Logger With A Symbolic Server Name

    3 Installation Figure 4: Accessing the data logger with a symbolic server name. Figure 5: Readout the IP address to the data logger with the program chiptool. Figure 6: Accessing the data logger with a fix IP address.

  • Page 11: Configuration Of Pc For A Direct Connection With Data Logger

    The program is searching for the data logger and if the PC is configured correctly and the right connection cable is used, the Schleibinger device appears in the window of the pro- gram. Click with the right mouse button on the entry within the window and choose IP configuration.

  • Page 12: Configuration Of The Data Logger For Direct Connection Us

    3 Installation Figure 8: Configuration of the data logger for direct connection using program chiptool.

  • Page 13: Principles Of Operation

    The reference temperature is measured at the bottom of the container in the middle of the CDF bath. Be sure that one container is in contact with the temperature probe. The cooling liquid is circulated by pump 1 (fig. 11). For heating the heater is switched on.

  • Page 14: Mechanical Construction

    Figure 10: Temperature cycle for the CDF test device. Figure 11: Cooling system from the CDF test device. 4.3 Mechanical construction The CDF test device is supplied as a plug-in compact device in chest form. It consists of three main parts (fig. 12): • testing bath •...

  • Page 15: Refrigerant Equipment

    To attach the panel, insert the nipples into the openings of the spring tabs. Lock the sheet by applying pressure to all edges of the panel. Do not press in the middle of the panel. Figure 14: Removing of the panels of the CDF test device.

  • Page 16: Filling The System

    4 Principles of operation 4.3.3 Filling the system The amount of cooling liquid is about 100 liters (see chapter 4.3.4). The cooling liquid is filled into the testing bath and passes through the over- flow into the cooling liquid buffer (fig. 15, left). Fill the cooling liquid until the optimal level in the buffer is reached (fig.

  • Page 17: Cube Test, Astm C 666 Procedure A

    4 Principles of operation especially with the lid open is possible. By handling the samples addi- tional water is added to the cooling liquid, thereby changing the concen- tration of the water-glycol mixture. Check the antifreeze of the cooling liquid regularly. For quick and safe control we recommend to use a re- fractometer (fig.

  • Page 18: Key Switch

    4 Principles of operation Figure 18: Level control of the cooling liquid and parameter setting for the higher heating power. 4.5 Key switch During operation, the touch screen can be protected against unautho- rized users. The touch screen can be blocked so that the operation on the touch screen is no longer possible.

  • Page 19: Transport Of The Cdf Test Device

    4 Principles of operation 4.6 Transport of the CDF test device In the case of a trasportation of the CDF test device, remove the cooling liquid from the bath and the storage tank (buffer). Only attach the system to the frame of the chest and avoid exerting...

  • Page 20: Operation Of The Controller

    Choose Start to start the system. The system starts at the specified cycle time. This time is retained even after switching off and can be changed in the menu cycle time (see chapter 5.3). For the CDF test 28 cycles of 12 hours each will be executed. The corresponding number of cycles will expire, if another profile is activated.

  • Page 21: Status

    The temperature profile and the number of cycles can be freely defined by the user in the menu Setup –> System Menu –> Profile inp. (see chapter 5.4.2). The CDF profile is activated by default. 5.2 Status From the status the current information about the status of the digital inputs and the temperatures can be obtained (fig.

  • Page 22: Setup

    Hint: selected temperature profile. For example in case of CDF test, when the system should start at 10 a.m. and the weathering should be determined at 1 to 3 p.m., the cycle time should be set to 7h and 30m. According to the temperature profile, 3 hours later the cycle time is 10h 30m and the real time is 1 p.m.

  • Page 23: Profile Input

    5 Operation of the controller 5.4.2 Profile input Some of the temperature profiles are factory-set at the CDF test equip- ment and can be selected directly from the touch screen (fig. 27). The current activated temperature profile is marked accordingly.

  • Page 24: Display

    Figure 29: Temperature profile. The number of cycles depends on the testing procedere for example CDF or CIF procedere. For continuous running the equipment at the same temperature profile the number of cycles can be set to 32000 max- imum.

  • Page 25: Clock

    Figure 30: Submenu - Display (left) and Graph. Display (right). 5.4.4 Clock The CDF machine differentiate between the cycle time and the real time. The cycle time can be adjusted from the submenu Cycle Time (see also chapter 5.3). The real time can be adjusted from the submenu Setup –>...

  • Page 26: Submenu For Manual Control Of The Testing Machine

    Do not user this menu if you have not previously dealt in detail with the system technology and are aware of the context. Improper handling leads to a fail of the system. Please contact Schleibinger for further questions. Figure 33: Submenu for manual control of the testing machine.
  • Page 27 Do not change the parameters! Please contact Schleibinger for sup- Attention! port! The schematic representation of the bath parameters is shown in fig. 36. The parameters set can be found from the calibration sheet of the CDF machine in the controller unit. submenu description...
  • Page 28 5 Operation of the controller Since December 2003, the CDF machines have been equipped with two different Y-K magnetic valves. Since January 2008, the CDF machines have been equipped with two identical Y-K magnetic valves. Each of the valves can be closed by a ball valves.
  • Page 29 Object parameter : The controller is implemented with a so called Luenberg observer. For this additional parameters for the CDF machine are required and can be adjusted in the submenu Object. The explanation of the parameters is shown in table 1:.
  • Page 30 5 Operation of the controller Probes The temperature of the CDF machine will be measured by PT100 sen- sors. The calibration values for the temperature sensors of the testing bath and the buffer will be safed in the submenu Setup –> System Menu –>...
  • Page 31 From the submenu Misc. additional settings for the CDF machine can be done. • Restart: If this submenu is activated, the CDF machine starts after the main power was off automatically. • Max.Temp.: defines the maximum temperature at which the CDF machine stops with an error message.

  • Page 32: Software Handling With Web Browser

    The CDF testing equipment can largely be connected via its built-in net- work interface. The user interface on the PC is the web browser soft- ware. Enter the IP address of the CDF equipment in the address field of the web browser for example 192.168.1.120. After successful connec- tion, the start screen is displayed (fig.

  • Page 33: Data

    6 Software handling with web browser Figure 42: Displaying of current measurement data. Figure 43: Graphical display of measured values. 6.2 Data The main menu Data contains the submenus Text, Logfile and Clear Data (fig. 44). Figure 44: Main menu - Data.
  • Page 34 6 Software handling with web browser All recorded measured values are displayed in tabular form after selec- tion Data - Text - Load (fig. 45). Figure 45: Anzeige der Messdaten in tabelarischer Form. In the first column the seconds since 01.01.1980 will be displayed. The second column is showing the cycle time in seconds.

  • Page 35: Profile

    Up to 8 temperature profiles can be defined in the menu Profiles (fig. 49. The individual temperature profiles can be entered or changed both on the CDF machine itself and via web browser. Select the desired profile 1 to 8. The data can now be entered in the corresponding fields (fig. 50).
  • Page 36 6 Software handling with web browser Figure 49: Selection of the temperature profile from the web browser. Figure 50: Entering of the temperature profile for the CDF test equip- ment. • The profile name can be specified unter the profile number. Use short and concise names as they will be displayed later on CDF touch screen.

  • Page 37: System

    If the changed profile is already selected from the touch screen on the CDF machine, the change will not take effect until CDF equipment is restarted (switch off and on again). If the new profile is to be driven, this profile must be selected via the touchscreen on the CDF machine itself.

  • Page 38: Technical Data

    7 Technical data 7 Technical data General dimension (w x d x h) 225 x 80 x 120 cm weight without cooling liquid approx. 560 kg protection IP20 temperature range -20 °C ... +20 °C (-40 °C at evaporator) temperate deviation <...

  • Page 39: Service Hints

    – 1.075 g/cm . Use of a refractometer is recom- mended. Check and adjust the filling quantity of the cooling liquid in the bath. To do this, stop the CDF ma- chine, place all the sample containers in the bath and check the level of the buffer.

  • Page 40: Maintenance Controller

    These parameters will not be safed perma- nently and have to be reentered after the change of the battery. • Switch off the CDF equipment. • Pull out the mains plug. • Open the controller unit and remove the acrylic glass cover from the main board of the controller.
  • Page 41 8 Service hints problem cause help fault low pres- freeze protection of check the density of the sure no.223 the cooling liquid to cooling liquid and adjust it to at least -40 °C pump 2 do not run check the fuse F4 valve Y-1 do not work change coil, check the voltage (24V)

  • Page 42: Schematics And Data Sheets

    9 Schematics and data sheets problem cause help display stays Power supply is off check fuse F6 dark after switching on the machinel fuse blown check melting fuses on the PCB board. connection interrupted check the D-Sub cable from the controller to the display.

  • Page 43: Refrigeration Diagram

    9.3 Refrigeration diagram 10 Manufacturer Schleibinger Geräte Teubert u. Greim GmbH Gewerbestrasse 4 84428 BUCHBACH Germany phone: +49 (0) 8086 9473110 fax: +49 (0) 8086 9473114 info@schleibinger.com http://www.schleibinger.com Copyright ©2019 Schleibinger Geräte Teubert und Greim GmbH, Buch- bach, Germany. All rights reserved.
  • Page 44 List of Figures CDF test equipment ..... Set up of the CDF machine....
  • Page 45 Measured values in tabular form for import..CDF logfile in tabular form....Submenu - Clear Data....
