HDMI Splitter
Model No.:LM-SP15-4K2K
Operating Instructions
Dear Customer
Thank you for purchasing this product. For optimum performance and
safety, please read these instructions carefully before connecting,
operating or adjusting this product. Please keep this manual for future
reference.
1
Operating Instructions
FEATURES
1. Support 3D technology
2. Distributes 1 HDMI source to 4 HDMI Displays simultaneously.
3. Supports all the mandatory and several optional 3D formats
described in HDMI 1.4 specifications.
4. Supports resolutions up to Ultra HD 4K x 2K (3840 x 2160 @
30Hz) and 1080p Full HD
5. Supports High Definition Resolutions : 1080p @ 60HZ,
720p/1080i @ 120Hz.
6. Supports Digital Audio Format, such as High Definition Audio
support: Dolby TrueHD, and DTS-HD Master Audio.
7. DC 5V Power.
NOTICE
Our company reserve the right to make changes in the hardware,
packaging and any accompanying documentation without prior written
notice.
2
Operating Instructions
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for LINK-MI LM-SP15-4K2K
Summary of Contents for LINK-MI LM-SP15-4K2K
- Page 1 FEATURES HDMI Splitter 1. Support 3D technology Model No.:LM-SP15-4K2K 2. Distributes 1 HDMI source to 4 HDMI Displays simultaneously. Operating Instructions 3. Supports all the mandatory and several optional 3D formats described in HDMI 1.4 specifications. 4. Supports resolutions up to Ultra HD 4K x 2K (3840 x 2160 @ 30Hz) and 1080p Full HD 5.
- Page 2 SPECIFICATIONS TABLE OF CONTENTS Operating -5 to +35℃(+23 to +95℉) Specifications Temperature Range Package Contents Operating Humidity 5 to 90%RH (No Condensation) Range Panel Descriptions Input Video Signal 0.5-1.0 Volts P-P Connecting and Operating Input DDC Signal 5 volts p-p(TTL) Typical Application Product Service Data transfer speed...
- Page 3 PACKING CONTENTS CONNECT AND OPERATE 1) Main Unit. 4-port HDMI splitter 1) Connect the HDMI signal sources(Such as PS3,STB etc) into 2) 5VDC Power Supply. HDMI input. 3) Operating Instructions 2) Connect the HDMI display device (such as :HD-LCD,HD-DLP) into HDMI outputs. PANEL DESCRIPTIONS 3) Insert the DC side of 5v power supply into Power input and then Front Panel...
- Page 4 During the "Parts" warranty period, there will be no charge for parts. 2) Servicing Personnel: Do not attempt to service the unit beyond You must mail-in your product during the warranty period. This that described in these operating instructions. Refer all other servicing Limited Warranty is extended only to the original purchaser and only to authorized servicing personnel.
- Page 5 2) THERE ARE NO EXPRESS WARRANTIES EXCEPT AS LISTED UNDER "LIMITED WARRANTY COVERAGE".THE WARRANTOR IS NOT LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES RESULTING FROM THE USE OF THIS PRODUCT, OR ARISING OUT OF ANY BREACH OF THIS WARRNTY. (As examples, this excludes damages for lost time, cost of having someone remove or re-install an installed unit if applicable, travel to and from the service, loss of or damage to media or images, data or other recorded content.
