  • Page 1 Manual Veloria Art. 0975 FB 04-267 Rev. 3 Date: 24.01.2019...
  • Page 2: Table Of Contents

    Directory Foreword Safety Instructions Cleaning & Disinfection Getting to Know the Unit Before First Use Area of Application Operation Operation Steps Working Positioning Suction Exchange Micro Filter Exchange Control Unit Filter Clamping the Bur/Tool Adjusting the Speed Foot Switch Maintenance & Care Cleaning the Chuck Maintenance Overview Handling Instructions...
  • Page 3: Foreword

    Veloria unit. If you have any questions or suggestions, you can contact us by telephone or email. This user manual belongs with the Veloria unit. Keep it somewhere safe. If you give this product to someone else, please include this document as it includes important infor- mation on how to correctly use the product.
  • Page 4: Safety Instructions

    Safety Instructions The installation of the working area has to cor- respond to the relevant regulations. Set up the unit in such a way, that the air slits are not blocked and the extracted air can escape well. To avoid the risk of electrocution only connect the device to the mains power supply.
  • Page 5 Safety Instructions When working with materials, which might cre- ate dust or moisture, use a drilling unit with suc- tion or spray technique. Wear a nose and mouth protection. Always follow the safety instructions, provided by the manufacturer of the materials being formed and used.
  • Page 6 Safety Instructions To ensure that the bur/tool sits firmly in the chuck, do not work with tools which • have an oily shaft, • are worn, • are bent. Before using the equipment, assure that • the tool can be pushed far enough into the chuck (Test this with a dipstick and clean if necessary.), •...
  • Page 7 Safety Instructions Only use the suction function if you have in- stalled the suction filter. Check this filter every 10 operating hours. If it is full, please exchange it. A filter should be exchanged at least after 50 operating hours. Never use the suction to vacuum any liquids (or air/water fog which contains particles of liquids).
  • Page 8: Cleaning & Disinfection

    Cleaning & Disinfection The device is designed to be compatible with rotating in- struments which do not penetrate the skin or mucosal or inadvertently may still cause injuries. For this application please adhere to the cleaning and disinfection instructions provided be- low.
  • Page 9: Getting To Know The Unit

    Getting to Know the Unit decrease the suction output increase the suction output reduce the speed increase the speed display of speed/suction level change direction of rotation LED is on during reverse rotation main switch ON/OFF button (Standby) connecting socket for foot switch...
  • Page 10: Before First Use

    Before First Use Please read through the instructions Operation carefully before using the unit and The working area must conform to carefully note the safety advice. the conditions described. Set up the Always keep this manual accessible unit in such a way, that the air slits to any users of the drill.
  • Page 11 Before First Use If you have a foot switch, insert its Take up the handpiece. Should the plug into the port on the right of the handpiece be twisted by the hose device which displays this symbol you can adjust that at the control unit.
  • Page 12: Use

    Operation Steps tion power you can start working. If you want to take a break or finish In the following section the order in the job, press the standby button which you should use the device is (9). The handpiece motor and suc- described.
  • Page 13: Working Positioning

    Work Positioning The following images are examples of how to work on various parts of the foot. Always make sure that the foot is firmly gripped and that you can work freely and without strain.
  • Page 15: Suction

    Suction Pull out the lid of the dust chamber and remove the old filter. Hold the Switch on the suction with button filter in the middle to prevent it from (2). The suction output can be regu- bending and sliding off (see picture lated in 5 levels.
  • Page 16: Clamping The Bur/Tool

    Foot Switch Operation of the foot switch Only use the original hadewe foot switch (art. 0970) to avoid damag- es. Insert the plug of the foot switch into the socket with this symbol...
  • Page 17: Maintenance & Care

    Maintenance & Care Cleaning the Chuck In the process of time, some dirt might collect itself within the hand- piece and might affect its functions. Therefore, the chuck has to be cleaned monthly. How to remove the chuck Screw off the top of the handpiece To assemble the chuck, follow the with the spanner shown in the pic- steps in reverse order.
  • Page 18: Maintenance Overview

    Maintenance & Care Rinse the chuck very well, and make sure you let it dry well after- wards. Cover your index finger with a very little amount (just a drop) of oil and rub in between your thumb and index finger. Dab off the oil until your fingers is only covered with a very thin film of oil.
  • Page 19: Handling Instructions

    In cases in which a down. A second disadvantage is the rust infestation was found within the...
  • Page 20: Troubleshooting

    The bur/tool itself can be tested with Foot switch is used constantly or the hadewe Bur Shaft Tester faulty. → Pull out the socket of (art. 4990) to see if it is bent. the foot switch to see if this is the cause.
  • Page 21: Technical Data

    2014/30/EU directive EMC fuse Sec.: Thermal fuse 2014/35/EU low voltage directive protection class I accuracy of speed display: ±10% hadewe GmbH – Grambartstraße 10 – 30165 Hannover handpiece: type B applied part diameter: 19 - 25 mm Accessories & Spare Parts length: 144 mm speed: 6.000 - 40.000 rpm...
  • Page 22 (WEEE Reg.-Nr. DE20392713, b2b device). For disposal of this unit out Keep dry! of Germany, please contact the site where you bought this hadewe ON/OFF button (standby) product. (no disconnection from main power supply) Note for the disposal of the device/...
