welltherm HT0606 0011 Series Manual

Infrared heating element
Table of Contents

Advertisement

Available languages

Available languages

Bedienungsanleitung Infrarotheizungen Typ HT
Manual for infrared heating elements type HT
Technische Daten
Technical Data
Modellnummer
Abmessungen (cm)
Leistung (W)
model number
dimension
power
HT0606_0011
60 x 60 x 1,5
1000
HT0606_2011
60 x 60 x 1,5
700
HT0609_0011
60 x 90 x 1,5
1500
HT_0609_2011
60 x 90 x 1,5
1000
HT0612_0011
60 x 120 x 1,5
2000
HT0612_2011
60 x 120 x 1,5
1400
www.welltherm.de
Nennspannung
Nennstrom (A)
Schutzklasse
voltage
current
protection class
4,4
3,1
6,5
230 V~ 50-60 Hz
4,4
8,7
6,1
Gewicht (kg)
Anschlußkabel
weight
connection leadweight
503,36
11
570,59
11
671,43
13
1,9m Kabel mit Schukostecker
1,9m cable with plug
797,48
13
494,96
15
747,06
15
Frontmaterial
front materialkabel
ESG-Glas 5mm max. 190°C
ESG-Glas 5mm max. 140°C
ESG-Glas 5mm max. 190°C
ESG-Glas 5mm max. 140°C
ESG-Glas 5mm max. 190°C
ESG-Glas 5mm max. 140°C
V2.4 - 25.06.2015 – 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HT0606 0011 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for welltherm HT0606 0011 Series

  • Page 1 60 x 90 x 1,5 1000 797,48 ESG-Glas 5mm max. 140°C HT0612_0011 60 x 120 x 1,5 2000 494,96 ESG-Glas 5mm max. 190°C HT0612_2011 60 x 120 x 1,5 1400 747,06 ESG-Glas 5mm max. 140°C www.welltherm.de V2.4 - 25.06.2015 – 1...
  • Page 2: Table Of Contents

    1. Safety advice 10 - 12 2. Introduction 3. General information 4. Intended use 5. Waste management 6. Scope of delivery 7. Cleaning and care 8. Terms of guarantee 9. Installation 15 - 16 www.welltherm.de V2.4 - 25.06.2015 – 2...
  • Page 3: Sicherheitshinweise

    1.5. Zur Vermeidung von Gefährdungen darf die Infrarotheizung weder geöffnet, noch selb- ständig verändert oder repariert werden. Beschädigte Netzzuleitungen dürfen nur vom Fachpersonal oder von einer ähnlich elektrotechnisch qualifizierten Person repariert werden! www.welltherm.de V2.4 - 25.06.2015 – 3...
  • Page 4 1.9. Die Mindestabstände gem. untenstehendem Bild sind unbedingt einzuhalten! NUR für TYP HT0612_0011A: Der Deckenabstand darf nur für diesen Typ bis min. 45mm betragen (Verwendung von optionalem Deckenhalterset Art. Nr. 11000020 möglich)! Deckenhalterset Art. Nr. 11000020 www.welltherm.de V2.4 - 25.06.2015 – 4...
  • Page 5 1.13 Das Stromkabel darf nicht auf der Rückwand abgelegt werden, es ist im 90 ° Winkel zur Heizung aus dem Temperaturbereich zu führen. 1.14 Infrarotheizungen dürfen nicht unmittelbar unterhalb einer Wandsteckdose angebracht werden! www.welltherm.de V2.4 - 25.06.2015 – 5...
  • Page 6: Einführung

    Die Mindestabstände von den Decken und Wänden gem. untenstehendem Bild sind unbe- dingt einzuhalten! 5. Entsorgung Bitte entsorgen Sie das Verpackungsmaterial und das Gerät/Geräteteile ordnungsgemäß. Elektrische Geräte enthalten sowohl Wertstoffe als auch umweltunverträgliche Stoffe. Des- halb gehören Sie nicht in den Restmüll! www.welltherm.de V2.4 - 25.06.2015 – 6...
  • Page 7: Lieferumfang

    7. Reinigung und Pflege der Eine regelmäßige Reinigung der IR-Elemente ist Voraussetzung für eine lange Lebensdauer Welltherm- Infrarotheizungen und einwandfreien Betrieb. Das Gerät sollte vor dem Reinigen sicherheitshalber ausgeschal- tet und abgekühlt sein. Die Außenseite kann durch Abwischen mit einem weichen, leicht an- gefeuchtetem Tuch oder Glasreiniger gereinigt und dann getrocknet werden.
  • Page 8: Installation

    Befestigungsschrauben ist Grundvoraussetzung für die spätere Montage. Wichtig: Die Bohrschablone besitzt 5 Markierungsbohrungen. Die mittleren Bohrungen sind die Markierungen für die optional erhältlichen Deckenhalterungen. Zur Markierung der Bohr- löcher ist die Schablone mit Ausstanzungen versehen (siehe Bild oben) www.welltherm.de V2.4 - 25.06.2015 – 8...
  • Page 9: Installation

    Um die Effizienz und die Verbrauchskosten der Systeme zu optimieren, empfehlen wir Ihnen den Einsatz von Funkthermostaten. Für die Deckenmontage ist ein zu- sätzlicher Befestigungssatz „Deckenhalter“ optional erhältlich. Gerne beraten wir Sie hierzu. Wir wünschen Ihnen viel Freude an Ihrer Infrarotheizung. www.welltherm.de V2.4 - 25.06.2015 – 9...
  • Page 10: Safety Advice

    Attention: avoid mechanical stress on the glass! If the glass is damaged immediately • separate it from the electrical network and don’t connect it again! • unmount the panel heater to avoid the risk of downfalling parts! www.welltherm.de V2.4 - 25.06.2015 – 10...
  • Page 11 11000020 is recommended)! accessories kit item no. 11000020 To meet the minimum distances the use of chains or steel cables is strongly recommended! Don’t hesitate to contact us for support concerning fixation methods! www.welltherm.de V2.4 - 25.06.2015 – 11...
  • Page 12 1.13. The power cord must not lie on the backside of the panel heater, it has to exit theheater in an angle of 90° 1.14. The infrared heating panels must not be positioned directly under a wall outlet. www.welltherm.de V2.4 - 25.06.2015 – 12...
  • Page 13: Introduction

    In this manual you will find important information on how to start run- ning your Welltherm infrared heater. The infrared heater will satisfy you by easy installation, flexibility in mounting and it is maintenance free. Please read this manual carefully before you get started for your safety.
  • Page 14: Scope Of Delivery

    It is recommended to use suitable chains or steel cables for taking down the heating panel (not included)! 7. Cleaning and care on Welltherm A frequent cleaning of the panel heater will ensure faultless operation and a long lifetime cir- infrared panel heaters cuit of your infrared panel heater.
  • Page 15: Installation

    4 times the weight of the heating ele- ment (about 25kg each)! Welltherm infrared heaters heat up solid material only. To get the best effect the living zone should be within the reach of the infrared beams directly.
  • Page 16: Installation

    To simplify the assembly of the ceiling heaters a separate accessories kit for ceiling assembly is optional available. Don’t hesitate to contact us for further information. Have a lot of fun with your infrared heater. www.welltherm.de V2.4 - 25.06.2015 – 16...
  • Page 17 Bedienungsanleitung Infrarotheizungen Typ HT Manual for infrared heating elements type HT www.welltherm.de V2.4 - 25.06.2015 – 17...
