Appendix A: Specifications

Table 20: Digital audio inputs

Characteristic
Impedance
Balanced inputs (XLR)
Term switched in
Term switched out
Unbalanced inputs
Input level
Balanced inputs
Unbalanced inputs
Reference input
Balanced input
Connector type
Input impedance
Input level
Unbalanced input
Connector type
Input impedance
Input level
Sample rate locking range,
all audio inputs
764 Digital Audio Monitor User Manual
Performance require-
ments
110 Ω ± 5%
Return loss >30dB
Return loss > 30dB
0.2 to 10 V
p–p
50 mV to 2 V
p–p p–p
110 Ω ± 10%
0.6 to 10 V
p–p
75 Ω ± 10%
0.2 V to 2 V
p–p p–p
27 kHz to 52 kHz
Supplemental information
0.1 MHz to 6 MHz
0.1 MHz to 6 MHz. Relative to
110 Ω load at loop-through
connector.
Relative to 75 Ω load at
loop-through connector.
XLR, terminated, no loop-
through
0.1 to 6 MHz
BNC, terminated, no loop-
through
0.1 to 6 MHz
75
