Reference

Headphones Submenu

Use the Headphonse submenu (Table 5) to determine the input
channels to be decoded and output through the headphone jack.

Table 5: Headphones submenu

Item
Audio Source
Manual Left Channel
Manual Right Channel

Input Submenu

Select the active connectors for the digital audio and reference inputs
through this submenu.

Table 6: Input submenu items (standard instrument)

Item
CH 1–2 input
CH 3–4 input
Reference input
In instruments equipped with Option 01 (embedded audio input), the
Input submenu is changed to accommodate the additional input
choice; the submenu also changes depending on the chosen input.
Table 7 describes the input submenu in Option 01 instruments when
the audio source selection is digital audio inputs. Table 8 describes
the submenu when digital video input is selected.
Please refer to Appendix C: Options, beginning on page 89, for more
information about Option 01.
56
Choices
AUTO (follows phase);
MANUAL
1; 2; 3; 4
1; 2; 3; 4
Choices
XLR-balanced
BNC-unbalanced
XLR-balanced
BNC-unbalanced
XLR-balanced
BNC-unbalanced
764 Digital Audio Monitor User Manual
Factory setting
AUTO (follows phase)
1
2
Factory setting
XLR-balanced
XLR-balanced
XLR-balanced
