- Page 1 i3SYNC FHD 4.0 User Manual Wireless presenting solution...
-
Page 2: Table Of Contents
Contents Product introduction ........................3 Package content receiver .............................................3 Hardware recommendation ..........................................3 Description of functions ............................................3 Hardware setup/installation ..........................................5 Screen Mirroring ..........................6 Pairing process .................................................6 How to present? ................................................6 Troubleshooting and FAQ......................7... -
Page 3: Product Introduction
Product introduction Thank you for purchasing your new i3SYNC FHD RX 4.0. This section will introduce you to this product and the wireless presenting solution. Package content receiver • i3SYNC FHD Receiver • +5V AC Power adapter (universal) • Micro USB cable •... - Page 4 HDMI OUT Main button: for pairing with transmitter Micro USB F1 button: for firmware update Slide switch: overwrite on /off Micro SD Card slot: for firmware update Status Color LED Action Standby Lights up constantly Pairing Green Blink Paired and Ready Green Lights up constantly Mirroring...
-
Page 5: Hardware Setup/Installation
Hardware setup/installation Receiver A. Connect a HDMI cable from a display to the HDMI OUT port of the Receiver. B. Connect the micro USB cable for power supply. C. The device will automatically start up after inserting the Power Supply. Transmitter A. -
Page 6: Screen Mirroring
Screen Mirroring Pairing process When using the i3SYNC FHD Rx 4.0 for the first time, you need to do the pairing process to make connection between your receiver and transmitter. A. Long press the main button of the receiver and transmitter simultaneously. -
Page 7: Troubleshooting And Faq
Troubleshooting and FAQ Transmitter didn’t receive HDMI data. Please check the HDMI is connected to the laptop or other device correctly Disconnected, LED is red Please check the HDMI connection and power cable connection of the transmitter and receiver@ What’s video mode and presentation mode ? The pictograms shows up after pressing the main button of the transmitter or right before the screen sharing will start. - Page 8 i3SYNC 4.0 & troubleshooting...
