SJE Rhombus Ultra Nator System Installation Instructions

ULTRA NATOR
™
This Ultra Nator control and alarm system provides a pre-wired contol panel for an indoor duplex pump application. The Ultra Nator
employs two receptacles to accept two 120 VAC pump plugs.
In normal operation pumps will alternate based on the pump switch level. If an alarm condition occurs (top fl oat activates), the alarm
light and horn turn on. The pump in use will turn off and the other pump will turn on. Pumping will continue until the pump switch
deactivates (bottom fl oat).
ULTRA NATOR FEATURES
™
 NEMA 1 rated for indoor use.
 Alternating pump action equalizes pump wear.
 Factory-installed 10ft power cord.
 Factory-installed pump activation and alarm activation switches for easy installations. (Various switch confi gurations available).
 Green power on indicator.
 Green pump run indicators (pump 1 & pump 2).
 Audible and visual high water alarm.
 Normal/silence alarm switch mounted externally for easy operation.
 Entire system is UL and cUL Listed to meet and/or exceed industry safety standards.
 Three-year limited warranty.
•
Periodically inspect the product. Check that the cable has not become worn or that the housing has not been damaged so as to impair the protection of the
product. Replace the product immediately if any damage is found or suspected.
•
Periodically check to see that the fl oats are free to move and operate the pump and alarm.
•
Use only SJE-Rhombus ® replacement parts.
SJE-RHOMBUS ® warrants to the original consumer that this product
shall be free of manufacturing defects for three years after the date of
consumer purchase. During that time period and subject to the conditions
set forth below, SJE-RHOMBUS
consumer, any component which proves to be defective due to defective
materials or workmanship of SJE-RHOMBUS
THIS WARRANTY DOES NOT APPLY: (A) to damage due to lightning
or conditions beyond the control of SJE-RHOMBUS
malfunctions resulting from failure to properly install, operate or maintain
the unit in accordance with printed instructions provided; (C) to failures
resulting from abuse, misuse, accident, or negligence; (D) to units which
are not installed in accordance with applicable local codes, ordinances,
or accepted trade practices, and (E) to units repaired and/or modifi ed
without prior authorization from SJE-RHOMBUS
System Installation Instructions
™

PREVENTATIVE MAINTENANCE

SJE-RHOMBUS THREE-YEAR LIMITED WARRANTY
®
®
will repair or replace, for the original
® .
®
; (B) to defects or
®
.
Some states do not allow limitations on how long an implied warranty
lasts, so the above limitation may not apply to you. Some states do not
allow the exclusion or limitation of incidental or consequential damages,
so the above limitation or exclusion may not apply to you. This warranty
gives you specifi c legal rights, and you may also have other rights which
vary from state to state.
TO OBTAIN WARRANTY SERVICE: The consumer shall assume all
responsibility and expense for removal, reinstallation, and freight. Any
item to be repaired or replaced under this warranty must be returned to
®
SJE-RHOMBUS , or such place as designated by SJE-RHOMBUS
ANY IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS
ARE LIMITED TO THE DURATION OF THIS WRITTEN WARRANTY.
SJE-RHOMBUS ® SHALL NOT, IN ANY MANNER, BE LIABLE FOR
ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES AS A RESULT
OF A BREACH OF THIS WRITTEN WARRANTY OR ANY IMPLIED
WARRANTY.
™
®
.
