M12
KUVINGS
WHOLE SLOW JUICER
MANUAL
After you read this manual,
keep where it can be easily accessed.
Household use only.

Advertisement

loading
Need help?

Need help?

Do you have a question about the ULD-1272CB and is the answer not in the manual?

Questions and answers

Summary of Contents for Kuvings ULD-1272CB

  • Page 1 KUVINGS WHOLE SLOW JUICER MANUAL After you read this manual, • keep where it can be easily accessed. • Household use only.
  • Page 2 Turn switch to OFF position after using juicer. Make sure the motor stops ㆍ If the appliance is given away as a gift, please include the manual with the product. completely before disassembling. ㆍThese instructions are also available on www.kuvings.com.
  • Page 3 SAFETY WARNING SAFETY WARNING The following precaution is provided to ensure the safety of the user. Please carefully read through the precautions and exercise a degree of care when using the appliance. Do not put the parts in the dishwasher or extremely hot water. →...
  • Page 4 PARTS * The products illustrated in this booklet may vary slightly from the actual product. * The products illustrated in this booklet may vary slightly from the actual product. 1. Drum Lid * Feeding Tube STEP 1 Top-set Assembly ● Align the red dots on each part and assemble in the order shown.
  • Page 5 HOW TO ASSEMBLE STEP 1 STEP 2 Top-set Assembly Top-set and Body Assembly For easy assembly hold the drum lid Turn the top set so that the arrow is aligned Check Before • Wash the parts before first use. by grabbing the feeding tube and turn with Close .
  • Page 6 HOW TO OPERATE Insert the prepared ingredients into the feeding tube, one piece at a time. After preparing the ingredients, plug the power cord into a wall outlet. · Prepare ingredients for optimal extraction. Note · Do not touch the power cord with wet hands. ·...
  • Page 7 TIPS ON OPERATION TIPS ON INGREDIENTS Juicer damage due to owner negligence or from not following the instructions in the owner’s manual Operating the juicer without ingredients can cause damage to the juicing screw. will void the warranty service. Do not continuously operate the juicer for more than 30 minutes. This can damage the motor from overheating.
  • Page 8 INGREDIENTS PREPARATION · Before Operating: If the juicer is jammed or if the drum lid does not open, Ingredients with small seeds Before (e.g. raspberry, pomegranate, grape): press the REVERSE button and hold until it becomes dislodged. Operating: | (E.g. apples, oranges & tomatoes) Repeat REVERSE-OFF-FORWARD as needed.
  • Page 9 INGREDIENTS PREPARATION · Juicing with the smart cap closed allows mixed juice creations with different How to Use Fibrous and/or tough leafy ingredients (e.g. celery, kale, pineapple): fruits, vegetables and liquids. the Smart · After juicing, close the smart cap to block excess juice from dripping, Cap: Fibrous ingredients like celery and kale should be cut into small lengths before juicing especially when disassembling the juicing bowl off the body.
  • Page 10 HOW TO DISASSEMBLE AND CLEAN * The products illustrated in this booklet may vary slightly from the actual product. Quick Rinsing Remove the juicing screw, strainer and Switch OFF and unplug the power cord Under running water, clean the outside rotation wiper unit from the juicing bowl.
  • Page 11 HOW TO CLEAN SILICONE PARTS HOW TO USE THE CLEANING TOOL * The products illustrated in this booklet may vary slightly from the actual product. Clean the rotation wiper under running water. The cleaning tool makes clean-up quick and easy. Thoroughly dry after cleaning.
  • Page 12 HOW TO USE THE BLANK STRAINER * Dissemble is opposite of Assemble. The blank strainer is used to process frozen fruits into sorbets, ice creams, and other frozen treats. Before use, make sure the silicone ring is correctly in place. To assemble the top set, place the juicing screw CAUTION and the blank strainer in the juicing bowl and...
  • Page 13 HOW TO USE THE COARSE STRAINER * Dissemble is opposite of Assemble. The coarse strainer is used for optimal juicing of hard fruits, vegetables, greens, and beans/nuts for making milks. Make sure to insert the coarse strainer into the rotation wiper before use. CAUTION To assemble the top set, place the juicing screw Drum Lid...
  • Page 14 HOW TO USE THE SMOOTHIE STRAINER * Dissemble is opposite of Assemble. CAUTION CAUTION To assemble the top set, place the juicing screw and Drum Lid the smoothie strainer in the juicing bowl and close When using frozen ingredients, make sure to thaw your frozen ingredients for about 5 to the lid.
  • Page 15 HOW TO USE LID OPENER TROUBLESHOOTING Q&A Use the lid opener if the lid doesn't open gently after juicing. When there is no power: The drum lid will not close: · Make sure the juicing screw is pushed all the ·...
  • Page 16 · Ingredients like celery or ginger contain long plugged in correctly. Model · Check that all the parts are correctly assembled. ULD-1272CB fibers that may wrap around the juicing screw · If too many ingredients are inserted at one time, and affect the juicer’s performance. When...
  • Page 17 EXTRACTEUR BASSE VITESSE KUVINGS MANUEL • Après avoir lu ce manuel, conservez-le à portée de main. • La couleur du produit peut être différente. • À usage domestique uniquement.
  • Page 18 Assurez-vous d’appuyer sur le bouton OFF après chaque utilisation de votre ㆍSi l'appareil est transmis à quelqu'un, veuillez remettre cette notice. extracteur de jus. Assurez-vous que le moteur est complètement à l’arrêt ㆍ Ces instructions se retrouve sous d'autres formats sur le site. avant le démontage. e.g.on a website. www.kuvings.com...
  • Page 19 AVERTISSEMENTS DE SÉCURITÉ INSTRUCTIONS DE SÉCURITÉ Les précautions suivantes sont fournies afin d’assurer la sécurité de l’utilisateur. Veuillez lire attentivement toutes les consignes et faire attention lorsque vous utilisez l’appareil. Ne pas mettre les pièces dans le lave-vaisselle ou dans une eau extrêmement chaude.
  • Page 20 PIÈCES * Les produits illustrés/photographiés dans ce manuel peuvent différer légèrement du produit réel. 1. Couvercle * Tube d'alimentation 4. Smart Cap (Capuchon) Détachable Panier Tube d'alimentation d'alimentation 2. Bol d’extraction 5. Base ÉTAPE 1 Assemblage du bloc supérieur 6. Bac à jus 3.
  • Page 21 ASSEMBLAGE ÉTAPE 1 ÉTAPE 2 Assemblage du bloc supérieur Assemblage du bloc supérieur avec la base Pour un assemblage facile, maintenez Marques d’ o uverture et de fermeture sur le CONSEIL Vérifiez l’assemblage • Lavez les éléments avant l'utilisation. le couvercle en attrapant le tube bloc supérieur.
  • Page 22 MODE D'EMPLOI Introduisez les aliments apprêtés les uns après les autres, un à la fois. Après avoir préparé vos aliments, branchez le câble d’alimentation à une prise murale. Notes | • Préparez des ingrédients pour une extraction optimale. • Si une quantité importante des ingrédients est placée dans le tube d'alimentation en même Notes | •...
  • Page 23 Après avoir pressé des aliments avec pépins tels que des raisins, faites un rinçage complet à l'eau sur le dessous de la vis de pressage. L'extracteur basse vitesse KUVINGS est un produit innovant qui utilise une technologie brevetée de pressage lent et efficace pour extraire le jus des aliments.
  • Page 24 PRÉPARATION DES INGRÉDIENTS • Avant utilisation: Si l'extracteur de jus est coincé ou si le couvercle ne s'ouvre Avant Ingrédients avec de petites graines (Par ex. framboises, grenades): pas, appuyez sur le bouton marche arrière [REVERSE] et maintenez-le enfoncé utilisation: jusqu'à...
  • Page 25 PRÉPARATION DES INGRÉDIENTS • L'extraction du jus avec le bouchon fermé permet de créer des mélanges avec Utilisation Ingrédients fibreux ou à feuilles dures (Par ex.: céleri, chou kale, ananas): différents fruits, légumes et liquides. du bouchon: • Après l'extraction du jus, fermez le bouchon pour éviter que l'excès de jus ne Les ingrédients fibreux comme le céleri et le chou devront être coupés en petits morceaux avant l'extraction.
  • Page 26 COMMENT DÉMONTER ET NETTOYER L’APPAREIL Rinçage rapide Éteignez l’appareil en le plaçant sur OFF Enlevez la vis de pressage, le tamis et le balai À l’eau courante, nettoyez l’extérieur de la vis de (arrêt) et débranchez le câble d’alimentation de rotation du bol d’extraction. Nettoyez avec pressage avec une éponge à...
  • Page 27 NETTOYAGE DES PIÈCES EN SILICONE UTILISATION DE LA BROSSE ROTATIVE * Les produits illustrés/photographiés dans ce manuel peuvent différer légèrement du produit réel. Conseil | Nettoyez le balais rotatif à l'eau courante. Conseil | La brosse rotative permet de nettoyer rapidement et plus facilement. Séchez complètement après avoir nettoyé.
  • Page 28 UTILISATION DU TAMIS À SORBETS * Désassemblez dans l'ordre inverse de l'assemblage. Avant l'utilisation, assurez-vous que le revêtement en silicone soit ajusté. ATTENTION Pour assembler la base supérieure, placez le tamis à sorbets et la vis de pressage dans le bol Couvercle Le tamis à...
  • Page 29 UTILISATION DU TAMIS À COULIS * Désassemblez dans l'ordre inverse de l'assemblage. Assurez-vous de placer le tamis à coulis dans le balais rotatif avant utilisation. ATTENTION Couvercle Pour assembler la base supérieure, placez le • Lorsque vous utilisez le tamis à coulis, assurez-vous de retirer les pépins ou noyaux tamis à...
  • Page 30 UTILISATION DU TAMIS À SMOOTHIES * Désassemblez dans l'ordre inverse de l'assemblage. ATTENTION Pour assembler la base supérieure, placez le Couvercle tamis à smoothies et la vis de pressage dans le Laissez les ingrédients congelés décongeler pendant 5 à 10 minutes avant l'utilisation. bol d'extraction puis fermez le couvercle.
  • Page 31 UTILISATION DE L'OUVRE COUVERCLE Q&R POUR RÉSOLUTION DES PROBLÈMES Utilisez l'ouvre couvercle lorsque le couvercle ne s'ouvre pas facilement après utilisation Si l’extracteur de jus n’est pas alimenté: Le couvercle ne se ferme pas: • Vérifi ez que le câble d’alimentation est branché •...
  • Page 32 • Des ingrédients tels que le céleri ou le gingembre Modèle qu’il est branché correctement. ULD-1272CB contiennent de longues fi bres qui peuvent s’enrouler autour de la vis de pressage et aff ecter • Vérifi ez que toutes les pièces sont assemblées la performance de l’extracteur de jus.
