INSTALLATION
SOLAR WATER HEATER
INDIRECT
THERMAL PIPE
LAGGING
SOLAR COLLECTOR
PANEL
MAINS
WATER
STOP COCK
PRESSURE CONTROL
VALVE 400 kPa
VACUUM BREAKER
EXPANSION RELIEF
VALVE 100 kPa
BALANCED COLD
TEMPERING VALVE
WATER TO TAPS
CONTROLLED HOT
WATER TO TAPS
˚
15 -
35
VACUUM BREAKER
SAFETY VALVE
THERMAL PIPE
LAGGING
HEAT TRANSFER FLUID
FEED TO SOLAR
COLLECTOR
DRAIN COCK
