Summary of Contents for Modular 65/40 BME
- Page 2 ¸ Code 252.108.11 ELECTRIC BAIN-MARIE MOD. 65/40 BME 65/70 BME 70/40 BME 70/70 BME 70/40 BME-T 70/70 BME-T 90/40 BME 90/80 BME 90/40 BMET 90/80 BMET 110/50 BME 110/90 BME...
-
Page 3: Table Of Contents
INDEX Paragraph Installation instructions Compliance with EEC directives Installation drawings Wiring diagrams Electrical specifications Technical data Preliminary installation instructions Regulations, technical rules and general specifications Installation 2.2.1 Electrical connection 2.2.1.1 Equipotential 2.2.2 Water connection for Model 90/80 BME and 110/90 BME Paragraph User instructions Start-up... - Page 4 INSTALLATION INSTRUCTIONS CONFORMITY WITH EEC DIRECTIVES REMARK: The electric bains-marie are made in compliance with the basic requirements envisaged by EEC directives, in accordance with “EEC Directive 73/23 on low voltage”, “EEC Directive 89/336 on electromagnetic compatibility” and are marked “CE” according to the EEC Directive 93/68.
-
Page 5: Electrical Specifications
The data plate shows all necessary data for installation and can be found on the terminal block cover, inside the compartment, in the models 70/40 BME and 70/70 BME, on the rear of the left- hand side panel in the models 65/40 BME and 65/70. Model... - Page 6 Model 90/40 BME 90/80 BME 90/40 BMET 90/80 BMET Rated voltage 230V -1~ 400V-3N~ 230V -1~ 400V-3N~ Total power kW Power cable H05RN-F H05RN-F H05RN-F H05RN-F Power cable 3 x 1 mm 5 x 1 mm 3 x 1 mm 5 x 1 mm Cross section Dimensions mm...
-
Page 7: Preliminary Installation Instructions
PRELIMINARY INSTALLATION INSTRUCTIONS The bain-marie must be positioned in a well-aired room, if possible under a hood to remove cooking steam thoroughly. Before starting the appliance, remove all protective film; thoroughly clean the surfaces with a soft cloth, lukewarm water and detergent, so as to remove all anti-rust products applied during the manufacturing stage, then dry with a clean cloth. -
Page 8: Electrical Connection
2.2.1 Electrical connection 1) The electric bains-marie are designed to operate off 400 VAC+3N voltage. 2) The connection to the mains must be carried out through a suitably rated trip switch which has at least 3 mm between the contacts. Moreover, the mains voltage - when the appliance is working - must not exceed ±... -
Page 9: Water Connection For Model 90/80 Bme And 110/90 Bme
2.2.2 WATER CONNECTION FOR MODELS 90/80 BME AND 110/90 BME To carry out a correct installation the following must be respected: 1) The water feed pipes must be connected to the mains using cut off cocks which should always be closed when the bain-marie is not being used or during maintenance interventions. 2) A mechanical filter must be installed between the cut off cock and the pipes feeding the bain- marie in order to avoid the build up of ferrous materials that when rusting could damage the stainless steel and lead to the presence of rust spots on the tank . -
Page 10: Start-Up
USER OPERATING INSTRUCTIONS 1) Bains-marie are appliances designed for heating food containers and should be exclusively used by trained personnel following these operating instructions. Any other use of the appliance is to be considered improper and therefore dangerous. 2) Before inserting containers or bowls make sure that the tank and false bottom have been carefully cleaned using hot water and detergent and then rinse well. -
Page 11: Maintenance, Cleaning And Care
MAINTENANCE, CLEANING AND CARE Before carrying out any cleaning operations disconnect the power at the mains. It is recommended that the installation be checked by an authorised technician at least twice a year, a special attention should be given to the efficiency of control and safety devices. . For the daily cleaning of the appliance, the steel parts must be cleaned using a smooth cloth, water and common detergents.
