2. Folding the bicycle

Folding the pedals
Fold down the bicycle's stand and fold the pedals in by
pushing the entire pedal towards the bike and then
folding it up or down.
Note: : Position the pedals horizontally with the left pedal
forward, so that it will not get in the way when the frame
is folded.
Handlebar clamp
Release the steering, first by rotating the locking ring (A)
away from the clamp. Open the clamp (B) so you can
fold the steering.
Frame clamp
Open the middle hinge mounting (right on the frame tube)
by moving the locking clip upwards. Pull the clamp (A + B)
outwards so that it comes loose. The frame is now open and
ready to fold.
Note: Do not use excessive force to release the clamp.
Folding the Frame
Stand to the left of the bike and fold the front wheel to the
rear wheel so that the wheels are close together. Under the
bottom bracket there is a triangular support on which the
bicycle can rest when folded.
Securing the wheels
Secure the bicycle by placing the wheels against
each other so that the magnets (A + B + D) connect
each other (C). It is advisable to provide the
handlebars and frame with protection during
transport by means of, for example a blanket.
6
