Hint: The 10 k resistor
The color code for the 10k resistor is:
BROWN = 1
BLACK = 0
BLACK = 0
RED = 2 (2 zeros in this case)
Brown = 1 (1% Tolerance)
= 1 0 0 0 0 with 1% tolerance
Hint: The 4.7 k resistor
The color code for the 4.7k resistor is:
YELLOW = 4
VIOLET = 7
BLACK = 0
BROWN = 1 (1 zero in this case)
Brown = 1 (1% Tolerance)
= 4 7 0 0 with 1% tolerance
Hint: The 390 k resistor
The color code for the 390k resistor is:
ORANGE = 3
WHITE = 9
BLACK = 0
ORANGE = 3 (3 zeros in this case)
Brown = 1 (1% Tolerance)
= 3 0 0 0 0 with 1% tolerance
10k resistor
4.7k resistor
390k resistor
