- Page 1 IMS Power Supply AP-DY6702 User Manual Shanghai Anping Static Technology.,Ltd 3/F,Building 27,No.69,Guiqing Road,Shanghai,China Tel：021-64517676 Fax：021-64517673...
-
Page 2: Product Picture
Product description ◆ The AP-DY6702 IMS power supply is a DC power supply for electrostatic monitoring and elimination systems produced by AP&T. It is an integrated power supply for power supply and signal transmission of pulsed DC ion fans, pulsed AC ion bars and static sensors. -
Page 3: Specifications
Specifications ◆ Basic Parameter Input voltage AC175-240V Output voltage DC24V Output current 12.5A Output Power 300W Product Size 380*160*50 Work instructions Input indication Digital display 0.28 Inch LED，monochrome Product network 32 Port ：P1-P32 port 1、2 5、6、9 White-oran White- White- Network port blue White-green, green brown... -
Page 4: Function Introduction
◆ Function introduction 1、Functional diagram 2、Network port cable function information Network port cable function information 1、2 Orange, white-orange VCC：+24VDC Blue RS485+B White-blue RS485+A Green White-green ：Sensor threshold alarm Brown ：Consumer high voltage alarm ACT： Sensor / static eliminator power up indication White-Brown Clean：Static eliminator cleaning instructions Metal shield... -
Page 5: Safety Warning
3、Features (1) The output voltage and output current are displayed in real time on the right side of the front panel of the power supply. The output voltage is fixed at 24V, and the output current is displayed in real time according to the load. -
Page 6: Installation Instructions
Installation instructions ◆ First, the hardware installation 1. Fix the IMS power supply firmly. 2. Plug the GB power cord into the socket on the rear panel of the IMS power supply and turn on the power. 3. Insert the adapter power cable RJ45 plug of the consumer into the P1—P16 RJ45 socket of the IMS power supply. - Page 7 2、Wireless connection 3、485Connection method External size chart ◆...
-
Page 8: After-Sale Service
Power maintenance ◆ If the IMS power supply confirms that the device is properly connected and the power supply is normal, the working status indicator on the front panel will be off if it is off. It should be stopped and repaired by professional maintenance personnel.
