- Page 1 AP&T Shanghai Anping Static Technology Co.,Ltd High Efficient Electroshock-proof Intelligent Ion Bar AP-AB1208 安平静电...
- Page 2 Widely used in electronics, optoelectronics, semiconductor and other industries Effectively solve the problem caused by static electricity Prevent sticking Static removal Prevent uneven scattering Prevent adhesion of objects Control ink splashing...
- Page 3 High efficient Safe Static removal...
-
Page 4: Intelligent Control
Intelligent Control Ion balance/ Ion output frequency adjustable The output ratio of positive and negative ions is adjustable, which can be used to adjust the ion balance voltage. Positive high voltage amplitude Positive high voltage amplitude (Positive high voltage) (Positive high voltage) The negative ion output increases with the increase of negative high voltage amplitude time... - Page 5 Intelligent Control Ion balance/ ion output frequency adjustable Button function instructions Symbol Operation instructions Function Unlock before adjusting operating parameters. Unlock Device starts running when power is on. Press "STOP" to standby and no high voltage Run / Pause output. Press "RUN" again and the device will start working. Press CTTH first, then +/- to increase or decrease the cleaning cycle.
- Page 6 Pulse AC The effect of static eliminating is better compare to power frequency AC ion bar Pulse AC Comparison with traditional AC Positive pulse Negative pulse Pulse AC Positive voltage working time (Positive high pressure) The pulsed AC method alternately applies "+" and "-" high voltage to one electrode needle to generate two polar ions.
- Page 7 Features Safe / Easy to use / Durable No.1 Easy installation Provide stainless steel bracket and can adapt to various installation environments. No.2 Electroshock-proof Protection against electroshock. No.3 Intake throttle valve The specification is Φ8-G1/8 grey. No.4 Working status visualization Red light alarm when high voltage abnormal.
-
Page 8: Specification
Specification Details / Parameter / Size Product Details Coding switch Communication and DC24V power network port Working status indicator Intake throttle valve Power indicator Strip grounding electrode Communication connection instruction Needle holder and electrode needle Positive and negative high voltage indicator light (flashing alternately with frequency) RJ45 port on the front panel of ion bar: Green light for power on and orange light for communication connection on the left port;... -
Page 9: Product Parameter
Product Parameter Model AP-AB1208 Input voltage DC 24V Power Electrode pin voltage Vpp:8-12KV Ion emission Pulse AC Emitter electrode Discharge structure Resistance coupling Output frequency 0.1,0.5,1,5,10,30,55,65,105Hz；(EX-Work setting: 30Hz) Discharge range L*W*H：Bar Length*300*1000mm Installation distance 100→100mm Ion balance ≤|±30V| （ AVE ）... -
Page 10: Installation Step
Installation step one adapter for one bar power cable cable cable one adapter for two bars Bracket installation power cable cable 1.Take out the ion bar, adapter power supply, power supply network cable , stainless steel mounting brackets and other accessories from the packing box. Insert one end of the power cord into the RJ45 socket of the power adapter 2.Install the stainless steel mounting brackets on the base mounting slot on the and the other end into the power RJ45 socket on the bar body. -
Page 11: Installation Position
Installation position 1. Choose the best static elimination position and install the bar body and the matching power adapter firmlyafter the static detection of the on-site working environment. The installation angle should be perpendicular to the surface of the charged body and the installation distance can be referred to the following table. -
Page 12: Packaging Accessories
Packaging accessories Name Image Part No. Specification Quantity GRT-240200: DC24V 2A, dual network Power Adapter OSP000601 port output, Size: 123*61*40.5mm (L*W*H) National standard power cord 8YXG25110 Standard:1.8m, optional:3m/5m Double ended crystal head 8WXI00004 Standard:2.5m, 5m/10m:optional black shield cable Single-ended crystal head FUTP CAT.5E 26AWG 4Pair Jacket PVC black shield 8WXI00002... -
Page 13: Troubleshooting
It can be used only after the electrical performance index is normal. After-sales service AP-AB1208 has undergone rigorous testing and aging treatment before ex-work. Its performance has completely reached the relevant indicators marked in the usage instruction. - Page 14 S pe cia lity C re a t es Va l u e S pe cia lity C re a t es Val ue Shanghai Anping Static Technology Co.,Ltd Tel : 021-64517676 Fax : 021-64517673 Postcode : 200233 Website : www.ap-static.com Address : 3/F,Building 27,No.69,Guiqing Road,Shanghai,China...
