Infinity Boss.three Assembly Manual page 3

NUTTED FRONT WHEEL
(for models without quick release front wheel)
(J)
1. If the Axle Nuts are already attached to the front
wheel axle, begin by removing them with an open end
wrench or adjustable wrench.
2. Set the wheel into the front fork
3. Install wheel retainer washers
(M)
are in the fork tab holes.
4. Attach the front wheel with the Axle Nuts
5. Tighten Axle Nuts with 15mm wrench provided.
NOTE: Ensure wheel spins freely without contacting
(G)
WARNING: Do not use Nuts
Put the wheel in the center of the fork and tighten
WARNING:
both nuts to the recommended torque.
Failure to obey these steps can allow the front wheel to loosen
WARNING:
while riding. This can cause injury to the rider or to others.
Seat post
O
marks on the seat post
Adjustment nut
Quick-release lever
3
(K)
(L)
making sure the tabs
(J)
.
without serrations to attach the front wheel.
SADDLE ASSEMBLY
The saddle assembly should be adjusted with the saddle centered on the rails and
level. Insert the saddle assembly into the frame.
Adjust seat to desired height
saddle may not turn left or right, or move up or down. If it moves after locking the
quick release lever, open it and tighten the adjusting nut further, then close the quick
release lever again.
Be sure that the seat post is inserted far enough into the frame so that the "minimum
insertion" mark on the seat post is no longer visible. Riding the bicycle with the seat
post above this line is dangerous and can cause serious injury, damage to the bicycle
Quick-release
and/or create an unstable riding position causing an accident.
seat clamp
N
Before each ride check to be sure the seat post is inserted so that the
Seat tube
minimum insertion mark cannot be seen. The quick release mechanism is
tightened securely to prevent accidental slippage.
Minimum
marks
