DynaMetric TLP-124HS Instruction Manual

Logger patch for cell phones & cordless phones

The TLP-124HS Logger Patch adapts most cordless and cell phones that use a headset

with a 2.5mm plug, to a tape recorder, sound card, or other audio device. It provides a

clear audio signal containing both sides of the phone conversation. The TLP-124HS

connects to the cell phone via the 2.5mm headset connector. See the diagram and

installation instructions below.

Unplug the 2.5mm headset plug from the cell phone and plug it into the jack on the

TLP-124HS.

Plug the black cable with the 2.5mm plug on the TLP-124HS into the cell phone

where the headset was plugged.

Plug the cable with the 3.5mm plug (gray, larger plug, longer cable) on the TLP-

124HS into the tape recorder, or MIC Input of a sound card or other audio device.
