Inspiron 13 5000
2-in-1
Setup and Specifications
Computer Model: Inspiron 13-5379
Regulatory Model: P69G
Regulatory Type: P69G001

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Inspiron 13 5000 and is the answer not in the manual?

Questions and answers

Related Manuals for Dell Inspiron 13 5000

Summary of Contents for Dell Inspiron 13 5000

  • Page 1 Inspiron 13 5000 2-in-1 Setup and Specifications Computer Model: Inspiron 13-5379 Regulatory Model: P69G Regulatory Type: P69G001...
  • Page 2 WARNING: A WARNING indicates a potential for property damage, personal injury, or death. Copyright © 2017 Dell Inc. or its subsidiaries. All rights reserved. Dell, EMC, and other trademarks are trademarks of Dell Inc. or its subsidiaries. Other trademarks may be trademarks of their respective owners.

  • Page 3: Table Of Contents

    Contents Set up your computer............ 5 Create a USB recovery drive for Windows..... 8 .......... 9 Reinstall Windows using a USB recovery drive Views................10 ......................10 Front ......................11 Left ......................12 Right ......................13 Base ..................... 14 Display .....................15 Bottom ......................16 Modes ...................
  • Page 4 Keyboard ....................23 Camera ....................23 Touch pad ..................24 Power adapter ....................24 Battery .....................25 Display ..................26 Communications ................26 Wireless module ................26 Computer environment Keyboard shortcuts............28 Getting help and contacting Dell........30 ..................30 Self-help resources ..................31 Contacting Dell...

  • Page 5: Set Up Your Computer

    Identifier GUID-6D17EB09-D7A9-4FB2-AC96-7A834ED483FB Status Released Set up your computer Connect the power adapter and press the power button.
  • Page 6 Finish operating system setup. For Windows: a) Connect to a network. b) Sign-in to your Microsoft account or create a new account. For Ubuntu: Follow the instructions on the screen to finish setup.
  • Page 7 Locate Dell apps in Windows. Table 1. Locate Dell apps Register your computer Dell Help & Support SupportAssist—Check and update your computer Create recovery drive for Windows. NOTE: It is recommended to create a recovery drive to troubleshoot and fix problems that may occur with Windows.

  • Page 8: Create A Usb Recovery Drive For Windows

    Create a USB recovery drive for Windows Dell recommends that you create a recovery drive to troubleshoot and fix problems that may occur with Windows. An empty USB flash drive with a minimum capacity of 16 GB is required to create the recovery drive.

  • Page 9: Reinstall Windows Using A Usb Recovery Drive

    Connect the USB recovery drive to your computer. Restart your computer. Press F12 after the Dell logo is displayed on the screen to access the boot menu. A Preparing one-time boot menu message appears. After the boot menu loads, select the USB recovery device under UEFI BOOT.

  • Page 10: Views

    Identifier GUID-E2D4C98A-FA78-45C3-A795-942B1B893B86 Status Released Views Identifier GUID-3A704352-DA32-4169-AB49-3E84AFF2FCEB Status Released Front Power and battery-status light/hard-drive activity light Indicates the battery-charge status or the hard-drive activity. NOTE: Press Fn+H to toggle this light between power and battery- status light and hard-drive activity light. Hard-drive activity light Turns on when the computer reads from or writes to the hard drive.

  • Page 11: Left

    Identifier GUID-8B031982-2F3E-4799-87BD-0515D5E9501A Status Released Left Power-adapter port Connect a power adapter to provide power to your computer and charge the battery. HDMI port Connect a TV or another HDMI-in enabled device. Provides video and audio output. USB 3.1 Gen 1 port with PowerShare Connect peripherals such as storage devices and printers.

  • Page 12: Right

    Press to put the computer in sleep state if it is turned on. Press and hold for 4 seconds to force shut-down the computer. NOTE: You can customize the power-button behavior in Power Me and My Dell at Options. For more information, see www.dell.com/ support/manuals.

  • Page 13: Base

    Identifier GUID-39A9F0E2-53D6-4C01-A908-727B81A73C60 Status Released Base Left-click area Press to left-click. Touchpad Move your finger on the touchpad to move the mouse pointer. Tap to left-click and two finger tap to right-click. Right-click area Press to right-click.

  • Page 14: Display

    Identifier GUID-14E6FE53-338A-4D64-854B-EDFCED8A8359 Status Released Display Left microphone Provides digital sound input for audio recording and voice calls. Infrared emitter (optional) Emits infrared light, which enables the infrared camera to sense depth and track motion. Infrared camera (optional) Depth-sensing feature of the camera enhances security when paired with Windows Hello face authentication.

  • Page 15: Bottom

    Released Bottom Left speaker Provides audio output. Service Tag label The Service Tag is a unique alphanumeric identifier that enables Dell service technicians to identify the hardware components in your computer and access warranty information. Right speaker Provides audio output.

  • Page 16: Modes

    Identifier GUID-EA9BD5D5-0F5C-4DE8-B109-0F72A656B206 Status Released Modes Notebook Tablet Stand...

  • Page 17: Tent

    Tent...

  • Page 18: Specifications

    Identifier GUID-B197B60C-5B62-4493-BB77-D54DEFF74DA2 Status Released Specifications Identifier GUID-6ED58E98-BCDA-4EAB-8ECC-08491CBB969E Status Released Dimensions and weight Table 2. Dimensions and weight Height 19.50 mm (0.77 in) Width 324 mm (12.76 in) Depth 224.70 mm (8.85 in) Weight (maximum) 1.68 kg (3.70 lb) NOTE: The weight of your computer varies depending on the configuration ordered and the manufacturing variability.

  • Page 19: System Information

    Identifier GUID-EBB9FBCB-F72D-4FD6-BE7D-80671311D486 Status Released System information Table 4. System information Processor 8th generation Intel Core i5/i7 Chipset Integrated in the processor Identifier GUID-6A9AE03D-DD5C-4B04-B520-EDBB4A30220F Status Released Operating system Table 5. Operating system Operating systems supported • Ubuntu • Windows 10 Pro Standard •...

  • Page 20: Ports And Connectors

    Identifier GUID-29BBC655-B1B5-40BC-8E34-F029BECD8444 Status Released Ports and connectors Table 7. Ports and connectors External • One USB 3.1 Gen 1 port • One USB 2.0 port • One USB 3.1 Gen 1 port with PowerShare Audio/Video • One HDMI port 1.4b port •...

  • Page 21: Audio

    Identifier GUID-D94510F9-A621-4D67-A911-FE18F1AC066F Status Released Audio Table 10. Audio specifications Realtek ALC3253-VA3 with Waves Controller MaxxAudio Pro Speakers Speaker Output • Average: 2 W • Peak: 2.5 W Microphone Digital-array microphones in camera assembly Volume controls Media-control shortcut keys and volume- control button Identifier GUID-0F8B9A09-518B-4EEB-81B1-5E5C53499E68...

  • Page 22: Media-Card Reader

    Identifier GUID-5F2E5AFA-3FA5-46BD-B86D-5DA39010A6F7 Status Released Media-card reader Table 12. Media-card reader specifications Type One SD card slot Cards supported SD card Identifier GUID-CCF57348-7F42-4EB0-9ECE-4F75C8F81632 Status Released Keyboard Table 13. Keyboard specifications Type • Backlit keyboard • Non-Backlit keyboard Shortcut keys Some keys on your keyboard have two symbols on them.

  • Page 23: Camera

    Identifier GUID-C26AC3D4-036E-44C5-BC8D-11A2A66C1775 Status Released Camera Table 14. Camera specifications Resolution Camera • Still Image: 0.92 megapixel • Video: 1280x720 (HD) at 30 fps (maximum) Infrared camera 640 x 480 (VGA) Diagonal viewing angle Camera 74 degrees Infrared camera 60 degrees Identifier GUID-C6FD722C-C955-48B6-ACAC-34CF64134A9C Status...

  • Page 24: Power Adapter

    Identifier GUID-0F842F02-1F6F-400D-9CCD-4DECD7ACDAF3 Status Released Power adapter Table 16. Power adapter specifications Type 45 W Diameter (connector) 4.5 mm Input voltage 100 VAC–240 VAC Input frequency 50 Hz–60 Hz Input current (maximum) 1.30 A Output current (continuous) 2.31 A Temperature range •...

  • Page 25: Display

    Operating time Varies depending on operating conditions and can significantly reduce under certain power-intensive conditions. Life span (approximate) 300 discharge/charge cycles Temperature range • Operating: 0°C to 35°C (32°F to 95°F) • Storage: –40°C to 65°C (–40°F to 149°F) Coin-cell battery CR-2032 Identifier GUID-A705BAA9-C262-48FF-8489-34FB211E8912...

  • Page 26: Communications

    Identifier GUID-6E77429C-D0EE-4B6E-88A5-AC52C95638BA Status Released Communications Table 19. Supported communications Wireless • Wi-Fi 802.11ac • Bluetooth 4.0 • Bluetooth 4.1 (optional) • Miracast Identifier GUID-C77ACCDE-59A4-4AEB-B5B2-C0B139287BD6 Status Released Wireless module Table 20. Wireless module specifications Type Intel 3165 QCA61x4A (DW1820) Transfer rate Up to 433 Mbps Up to 867 Mbps Frequency bands...
  • Page 27 Table 21. Computer environment Operating Storage Temperature range 0°C to 35°C (32°F to –40°C to 65°C (–40°F to 95°F) 149°F) Relative humidity 10% to 90% (non- 0% to 95% (non- (maximum) condensing) condensing) Vibration (maximum) 0.66 GRMS 1.30 GRMS † ‡...

  • Page 28: Keyboard Shortcuts

    Identifier GUID-4CD66D5D-EDC4-4E82-8C20-F42F2F18449C Status Released Keyboard shortcuts NOTE: Keyboard characters may differ depending on the keyboard language configuration. Keys used for shortcuts remain the same across all language configurations. Table 22. List of keyboard shortcuts Keys Description Mute audio Decrease volume Increase volume Play previous track/chapter Play/Pause...
  • Page 29 Keys Description Turn off/on wireless Pause/Break Sleep Toggle scroll lock Toggle between power and battery- status light/hard-drive activity light System request Open application menu Toggle Fn-key lock Home Page down Page up...

  • Page 30: Getting Help And Contacting Dell

    Identifier GUID-AF18382F-D265-43C2-85DA-28FFB5875F37 Status Released Getting help and contacting Dell Self-help resources You can get information and help on Dell products and services using these self-help resources: Table 23. Self-help resources Information about Dell products and www.dell.com services Dell Help & Support app...

  • Page 31: Contacting Dell

    BIOS information Product ID into the search bar. Contacting Dell To contact Dell for sales, technical support, or customer service issues, see www.dell.com/contactdell. NOTE: Availability varies by country and product, and some services may not be available in your country.
