Panasonic TH-58PH10EK Service Manual

Specifications

Power Source
Power Consumption
Power on
Stand-by condition
Power off condition
Plasma Display panel
Screen size
(No. of pixels)
Operating condition
Temperature
Humidity
Applicable signals
Color System
Scanning format
PC signals
Connection terminals
AV IN
PC IN
220-240 V AC, 50/60 Hz
630 W
Save OFF 0.8 W, Save ON 0.6 W
0.3 W
Drive method: AC type 58-inch,
16:9 aspect ratio
1,287 mm (W) × 723 mm (H) × 1,476 mm (diagonal)
1,049,088 (1,366 (W) × 768 (H)) [4,098 × 768 dots]
0 °C - 40 °C
20 % - 80 %
NTSC, PAL, PAL60, SECAM, Modified NTSC
525 (480) / 60i 60p, 625 (575) / 50i
30p 24sF .... SMPTE274M, 1250 (1080) / 50i
VGA, SVGA, XGA,
SXGA, UXGA ..... (compressed)
Horizontal scanning frequency 15 - 110 kHz
Vertical scanning frequency 48 - 120 Hz
VIDEO IN (BNC)
S VIDEO IN (MINI DIN 4PIN)
AUDIO IN (RCA PIN JACK × 4)
(HIGH-DENSITY MINI-D-SUB 15PIN)
VBS (use HD port)
High Definition Plasma Display
TH-58PH10BK
TH-58PH10EK
GPH10D Chassis
50p, 750 (720) / 60p 50p, 1125 (1080) / 60i
1.0 Vp-p (75-ohm)
Y: 1.0 Vp-p (75-ohm), C: 0.286 Vp-p (75-ohm)
0.5 Vrms (high impedance)
Y or G with sync 1.0 Vp-p (75-ohm)
Y or G without sync 0.7 Vp-p (75-ohm)
B / P / C :0.7 Vp-p (75-ohm)
B B
R / P / C :0.7 Vp-p (75-ohm)
R R
HD / VD:1.0 - 5.0 Vp-p (high impedance)
with picture 1.0 Vp-p (high impedance)
© 2007 Matsushita Electric Industrial Co., Ltd. All
rights reserved.
distribution is a violation of law.
ORDER NO. PCZ0706065CE
50i 24p 25p
Unauthorized copying and
