Napoleon VECTOR LHD45 Quick Start Manual

vECTOR 45 DIRECT vENT GAS FIREPLACE
TM

Specifications

Model BTU
LHD45 24,000
Overview
Dimensions
SAFETY BARRIER
Width
Actual Framing Actual
46 1/4 46 3/4 40 13/16 41 1/4
Mantel, see
"MINIMUM
MANTEL
CLEARANCES"
section.
Framing, see
"FRAMING"
section.
Side Wall
40 13/16"
1036mm
39 5/16"
999mm
24 Napoleon Road, Barrie, Ontario, Canada L4M 0G8 • 214 Bayview Drive, Barrie, Ontario, Canada L4N 4Y8
Fireplaces, Heating and Cooling: 705-721-1212 • Grills: 705 726-4278 • napoleonproducts.com
Height Depth
Framing Actual
19 7/8
Enclosures, see the section "MINIMUM
CLEARANCES TO COMBUSTIBLE
ENCLOSURES" section for drywall (or
other combustible material).
Venting, see
"VENTING" section.
Rating plate, see "RATING
PLATE INFORMATION"
section.
10 1/8"
257mm
17 13/16"
452mm
GAS INLET
7 1/2"
191mm
18 7/8"
479mm
19 7/8"
505mm
Glass
Framing
20 1/8 17 13/16 x 40 7/8
Framing, see
"FRAMING"
section.
Enclosures, see
the section
"MINIMUM
CLEARANCE TO
COMBUSTIBLE
ENCLOSURES"
section for
non-combustible
materials such as
tile, marble,
granite, etc.
34 1/16"
865mm
178mm
102mm
46 1/4"
1175mm
7"
Ø
Ø 4"
05/2015
