OPERATION

WARNING! If any parts are damaged or missing do not
operate the product until the parts are replaced. Failure to heed
this warning could result in serious personal injury.
Adjusting the chain tension
See pages 8 - 9.
Remove the battery pack before you do any work on the chainsaw.
Make sure the bar mounting nuts are loosened to finger-tight.
To increase the chain tension, turn the chain tensioning screw
clockwise and check the chain tension frequently. To reduce the
chain tension, turn the chain tensioning screw counterclockwise
and check the chain tension frequently.
The chain tension is correct when the gap between the cutter in the
chain and the bar is about 4 - 5.5 mm. Pull the chain in the middle
of the lower side of the bar downwards (away from the bar) and
measure the distance between the bar and the chain cutters.
Tighten the bar mounting nuts by turning it clockwise.
NOTE: The temperature of the chain increases during normal
operation causing the chain to stretch. Check the chain tension
frequently and adjust as required. A chain tensioned while warm
may be too tight upon cooling. Make sure that the chain tension is
correctly adjusted as specified in these instructions.
Adding the chain lubricating oil
of a
See pages 10 - 11.
mize
WARNING! Never work without chain lubricant. If the saw
rom
chain is running without lubricant, the guide bar and the saw
hain
chain can be damaged. It is essential to frequently check the
oil level in the oil level gauge and before starting to use the
chainsaw.
ack
saw
Clear surface around the oil cap to prevent contamination.
Unscrew and remove the cap from the oil tank.
Pour the oil into the oil tank and monitor the oil level gauge. Ensure
that no dirt enters the oil tank while filling.
ng a
Put the oil cap back on and tighten it up. Wipe away any spillage.
ing.
into

Installing the battery pack

own
See page 12.
rain
Place the battery pack in the product. Align raised ribs on the
battery pack with grooves in the product's battery port.
Make sure the latch of the battery pack snaps in place and that
wer
the battery pack is fully seated and secure in the product before
hing
beginning operation.
ase
hain
Holding the chainsaw
h of
See figure 1.
sion
Always hold the product with your right hand on the rear handle
and your left hand on the front handle. Grip both handles with the
thumbs and fingers encircling the handles. Ensure that your left
hand is holding the front handle so that your thumb is underneath.
ing.
the
Starting the product
not
See page 13.
hain
hain
Before starting the product, you should install the battery pack in the
both
product and make sure the chain brake is in run position by pulling
the chain brake lever/hand guard toward the front handle.
To start the product: pull the trigger release, and then press the
throttle trigger.
ack
Checking and operating the chain brake
See page 14.
Engage the chain brake by rotating your left hand around the front
handle. Allow the back of your hand to push the chain brake lever/
hand guard toward the bar while the chain is rotating rapidly. Be
sure to maintain both hands on the saw handles at all times.
Reset the chain brake back into the run position by grasping the
top of the chain brake lever/hand guard and pulling toward the front
handle until you hear a click.
WARNING! If the chain brake does not stop the chain
immediately, or if the chain brake will not stay in the run
position without assistance, bring the product to an authorised
service centre for repair prior to use.

TRANSPORTATION AND STORAGE

Stop the product, remove the battery pack, and allow the product to
cool down before storing or transporting.
Clean all foreign material from the product. Store it in a cool dry
and well-ventilated place that is inaccessible to children. Keep away
from corrosive agents, such as garden chemicals and de-icing salts.
Do not store outdoors.
Fit the guide bar cover before storing the product or during
transportation.
For transportation, secure the product against movement or falling
to prevent injury to persons or damage to the product.

MAINTENANCE

WARNING! Use only original manufacturer's replacement
parts, accessories, and attachments. Failure to do so can
cause possible injury, poor performance and may void your
warranty.
WARNING! Servicing requires extreme care and knowledge
and should be performed only be a qualified service technician.
For service, we suggest you bring the product to your nearest
authorised service centre for repair. When servicing, use only
identical replacement parts.
WARNING! Remove
maintenance or cleaning. Failure to do so could result in
serious personal injury.
■ You may only make adjustments or repairs described in this
manual. For other repairs, contact the authorised service agent.
■ Consequences of improper maintenance may cause the chain
brake and other safety features to not function correctly, thus
increasing the potential for serious injury. Keep your chainsaw
professionally maintained and safe.
■ Sharpening the chain safely is a skilled task. Therefore, the
manufacturer strongly recommends that a worn or dull chain is
replaced with a new one, available at your authorised service
centre. The part number is available in the product specification
table in this manual.
■ Follow instructions for lubricating and chain tension checking
and adjustment.
■ After each use, clean the product with a soft dry cloth.
■ Check all nuts, bolts, and screws at frequent intervals for
security to ensure the product is in safe working condition. Any
part that is damaged should be properly repaired or replaced by
an authorised service centre.
Replacing the guide bar and saw chain
See pages 15 - 18
Make sure to remove the battery. Wear protective gloves.
Remove the bar mounting nuts using the combination wrench
provided.
Remove the chain cover.
Remove the bar and saw chain from the product.
31
the battery before adjustment,
