Parts of the Porta02
jacks. They should be used together
IN
with the TRIM controls (see 3.3, "Setting
the level") to adjust the levels of the sig-
nals routed to the tape tracks.
[16] RECORD indicator
This red indicator lights when the
and
RECORD PLAY
at least one of the
switches is not in the
Pressing
RECORD
switches are set to
REC FUNCTION
has the same effect as pressing
[17] Transport controls
These work in the same way as the con-
trols on most cassette recorders. How-
ever, there are a few points you should
note:
• Pressing the
RECORD
press down the
12
keys are pressed, and
REC FUNCTION
position.
SAFE
and while both
PLAY
SAFE
.
PLAY
key will also
key.
PLAY
• If the left record-protect tab of the cas-
sette has been broken out, or if there is
no cassette loaded, the
cannot be pressed.
• It is not possible to go directly from
recording into playback mode.
• The key only pauses playback
PAUSE
and recording. It is not possible to
pause the tape in fast forward and
rewind modes.
• All keys lock down when pressed,
except for the
STOP
work when locked down.
[18] Cassette compartment
cover
The hinged cassette compartment cover
is opened by lifting the tab on the right
side.
There is no eject mechanism. You load
and unload cassettes by hand, using a fin-
ger or fingers in the space to the right of
the cassette.
key
RECORD
key, and only
